Supports Amd Socket Am4 Ryzen Series Cpus (Summit Ridge Raven Ridge And Pinnacle Ridge) Supports Ddr4 3466+ (Oc) (Ryzen Cpu) 1 Pcie 3.0 X16 Graphics Output: 2 Hdmi 7.1 Ch Hd Audio (Realtek Alc1220 Audio Codec) Nichicon Fine Gold Series Audio Caps 4 Sata3 1 Ultra M.2 (Pcie Gen3 X4) 6 Usb 3.1 Gen1 (1 Type-C 2 Front 3 Rear) Intel Gigabit Lan Armour Your Vr Machine Prepare Yourself Well To Enjoy The Impressive World Of Virtual Reality. Before That You Have To Make Sure Everything Is Qualified Including Hardware Software And Drivers. Motherboard Is The Key To Connect Every Critical Components And Asrocks Vr Ready Motherboards Are Definitely The One Youre Looking For. The Premium Quality Is Assured By Rigorous Testing During Development. The Sturdy Components And Rock-Solid Performance Makes You Completely Immersive In The Vr Scenario. Users Can Be Assured To Experience Vr Enjoyments Without Any Compatibility Problems. Rgb Led Build Your Own Colorful Lighting System! Rgb Led And Header Allows Users To Connect Led Strip And Create Their Unique Pc Style Easily. The Asrock Rgb Led Utility Can Be Downloaded Directly Or From An All-In-One Utility Asrock Live Update & App. Ultra M.2 32 Gb/S (Pcie Gen3 X4 & Sata3) The Pcie Gen3 X4 Ultra M.2 Interface Pushes Data Transfer Speeds Up To 32Gb/S. In Addition It Also Supports Sata3 6Gb/S M.2 Modules. 2Oz Copper It Comes With 2 Ounces Copper Inner Layers Using Only Carefully Selected Copper Materials For Pcb Layers Delivering Lower Temperature And Higher Energy Efficiency For Overclocking. Specification Unique Feature Asrock Super Alloy
- Premium Power Choke
- Dual-N Mosfet
- Nichicon 12K Black Caps (100% Japan Made High Quality Conductive Polymer Capacitors)
- Matte Black Pcb
- High Density Glass Fabric Pcb
- 2Oz Copper Pcb Asrock Ultra M.2 (Pcie Gen3 X4 & Sata3) Asrock Full Spike Protection (For All Usb Audio Lan Ports) Asrock Live Update & App Shop Cpu Supports Amd Socket Am4 A-Series Apus (Bristol Ridge) And Ryzen Series Cpus (Matisse Picasso Summit Ridge Raven Ridge And Pinnacle Ridge) Digi Power Design 8 Power Phase Design Chipset Amd Promontory A320 Memory Dual Channel Ddr4 Memory Technology 2 X Ddr4 Dimm Slots Amd Ryzen Series Cpus (Matisse) Support Ddr4 3200 / 2933 / 2667 / 2400 / 2133 Ecc & Non-Ecc Un-Buffered Memory Amd Ryzen Series Cpus (Pinnacle Ridge) Support Ddr4 3466+(Oc) / 3200(Oc) / 2933 / 2667 / 2400 / 2133 Ecc & Non-Ecc Un-Buffered Memory Amd Ryzen Series Cpus (Picasso) Support Ddr4 2933 / 2667 / 2400 / 2133 Non-Ecc Un-Buffered Memory Amd Ryzen Series Cpus (Summit Ridge) Support Ddr4 3466+(Oc) / 3200(Oc) / 2933(Oc) / 2667 / 2400 / 2133 Ecc & Non-Ecc Un-Buffered Memory Amd Ryzen Series Cpus (Raven Ridge) Support Ddr4 3466+(Oc) / 3200(Oc) / 2933 / 2667 / 2400 / 2133 Non-Ecc Un-Buffered Memory Amd 7Th Gen A-Series Apus Support Ddr4 2400 / 2133 Non-Ecc Un-Buffered Memory Max. Capacity Of System Memory: 32Gb 15 Gold Contact In Dimm Slots Bios 128Mb Ami Uefi Legal Bios With Gui Support Supports “Plug And Play” Acpi 5.1 Compliance Wake Up Events Supports Jumperfree Smbios 2.3 Support Cpu Dram Pch 1.05V Prom 2.5V Voltage Multi-Adjustment Graphics Integrated Amd Radeon Vega Series Graphics In Ryzen Series Apu Integrated Amd Radeon R-Series Graphics In A-Series Apu Directx 12 Pixel Shader 5.0 Shared Memory Default 2Gb. Max Shared Memory Supports Up To 16Gb. Supports 2 X Hdmi 1.4 With Max. Resolution Up To 4K X 2K (4096X2160) @ 24Hz / (3840X2160) @ 30Hz Supports Auto Lip Sync Deep Color (12Bpc) Xvycc And Hbr (High Bit Rate Audio) With Hdmi 1.4 Ports (Compliant Hdmi Monitor Is Required) Supports Hdcp 1.4 With Hdmi 1.4 Ports Supports Full Hd 1080P Blu-Ray (Bd) Playback With Hdmi 1.4 Ports Audio 7.1 Ch Hd Audio With Content Protection (Realtek Alc1220 Audio Codec) Premium Blu-Ray Audio Support Supports Surge Protection Nichicon Fine Gold Series Audio Caps 120Db Snr Dac With Differential Amplifier Pure Power-In Direct Drive Technology Pcb Isolate Shielding Impedance Sensing On Rear Out Port Individual Pcb Layers For R/L Audio Channel Lan Gigabit Lan 10/100/1000 Mb/S Gigalan Intel I211at Supports Wake-On-Lan Supports Lightning/Esd Protection Supports Energy Efficient Ethernet 802.3Az Supports Pxe Slots Amd Ryzen Series Cpus (Matisse Summit Ridge And Pinnacle Ridge)
- 1 X Pci Express 3.0 X16 Slot (Pcie1: X16 Mode) Amd 7Th A-Series Apus / Raven Ridge Cpus
- 1 X Pci Express 3.0 X16 Slot (Pcie1: X8 Mode) Amd Ryzen Series Cpus (Picasso Raven Ridge)
- 1 X Pci Express 3.0 X16 Slot (Pcie1: X8 Mode) Amd Athlon Series Cpus
- 1 X Pci Express 3.0 X16 Slot (Pcie1: X4 Mode) Storage 4 X Sata3 6.0 Gb/S Connectors Support Raid (Raid 0 Raid 1 And Raid 10) Ncq Ahci And Hot Plug 1 X Ultra M.2 Socket Supports M Key Type 2280 M.2 Sata3 6.0 Gb/S Module And M.2 Pci Express Module Up To Gen3 X4 (32 Gb/S) (With Matisse Picasso Summit Ridge Raven Ridge And Pinnacle Ridge) Or Gen3 X2 (16 Gb/S) (With A-Series Apu And Athlon Series Apu) Connector 1 X Lpc Header 1 X Amd Fan Led Header 1 X Cpu Fan Connector (4-Pin) 1 X Chassis Fan Connector (4-Pin) 1 X Chassis/Water Pump Fan Connector (4-Pin) (Smart Fan Speed Control) 1 X 24 Pin Atx Power Connector 1 X 8 Pin 12V Power Connector (Hi-Density Power Connector) 1 X Front Panel Audio Connector 1 X Amd Led Fan Usb Header 1 X Usb 2.0 Header (Supports 2 Usb 2.0 Ports) (Supports Esd Protection) 1 X Usb 3.1 Gen1 Header (Supports 2 Usb 3.1 Gen1 Ports) (Supports Esd Protection) Rear Panel I/O 1 X Ps/2 Mouse/Keyboard Port 2 X Hdmi Ports 1 X Optical Spdif Out Port 2 X Usb 2.0 Ports (Supports Esd Protection) 1 X Usb 3.1 Gen1 Type-A Port (Supports Esd Protection) 1 X Usb 3.1 Gen1 Type-C Port (Supports Esd Protection) 2 X Usb 3.1 Gen1 Ports (Supports Esd Protection) 1 X Rj-45 Lan Port With Led (Act/Link Led And Speed Led) Hd Audio Jacks: Rear Speaker / Central / Bass / Line In / Front Speaker / Microphone Software And Uefi Software
- A-Tuning
- Asrock Rgb Led
- Asrock Xfast Lan Uefi
- Asrock Full Hd Uefi
- Asrock Instant Flash
- Asrock Easy Raid Installer Support Cd Drivers Utilities Antivirus Software (Trial Version) Google Chrome Browser And Toolbar Accessories Quick Installation Guide Support Cd I/O Shield 2 X Sata Data Cables 1 X Screw For M.2 Socket Hardware Monitor Temperature Sensing: Cpu Chassis Chassis/Water Pump Fans Fan Tachometer: Cpu Chassis Chassis/Water Pump Fans Quiet Fan (Auto Adjust Chassis Fan Speed By Cpu Temperature): Cpu Chassis Chassis/Water Pump Fans Fan Multi-Speed Control: Cpu Chassis Chassis/Water Pump Fans Voltage Monitoring: +12V +5V +3.3V Cpu Vcore Form Factor Mini-Itx Form Factor: 6.7-In X 6.7-In 17.0 Cm X 17.0 Cm 2Oz Copper Pcb Os Microsoft Windows 10 64-Bit Certifications Fcc Ce Erp/Eup Ready (Erp/Eup Ready Power Supply Is Required)
