Asrock H510M-ITX/ac Intel H510 LGA 1200 mini ITX

Supports 10Th Gen Intel Core Processors And 11Th Gen Intel Core Processors 6 Phase Dr.Mos Power Design Supports Ddr4 3200Mhz (Oc) 1 X Pcie 4.0 X16 Graphics Output Options: Hdmi Displayport 7.1 Ch Hd Audio (Realtek Alc897 Audio Codec) 4 Sata3 1 X Ultra M.2 (Pcie Gen3 X4 & Sata3) 4 X Usb 3.2 Gen1 (2 X Rear 2 X Front) 4 X Usb 2.0 (2 X Rear 2 X Front) Intel Gigabit Lan Intel 802.11Ac Wifi + Bt 4.2 Asrock Polychrome Sync Dr. Mos Dr.Mos Is The Integrated Power Stage Solution Which Is Optimized For Synchronous Buck-Set Down Voltage Applications! Compared To Traditional Discrete Mosfets It Intelligently Delivers Higher Current For Each Phase Thus Providing Improved Thermal Result And Superior Performance. Premium 60A Power Choke Compared To Traditional Chokes Asrocks Premium 60A Power Chokes Effectively Make The Saturation Current Up To Three Times Better Thus Providing Enhanced And Improved Vcore Voltage To The Motherboard. Rule Your Own Lighting Way - Polychrome Rgb This Motherboard Features Onboard Rgb Headers And An Addressable Rgb Header That Allow Motherboard To Be Connected To Compatible Led Devices Such As Strip Cpu Fans Coolers Chassis And So On. Users May Also Synchronize Rgb Led Devices Across The Polychrome Rgb Sync-Certified Accessories To Create Their Own Unique Lighting Effects. Dual Band 802.11Ac Wifi No One Has Time For Weak Wifi Signals And Sluggish Internet! That’s Why This Motherboard Comes With A 802.11Ac Wifi (2.4G / 5G Wifi) Module Which Supports Wireless Networks And Bluetooth V4.2. Intel Lan Intel Lan Provides The Best Throughput Performance Lower Cpu Utilization Enhanced Stability And Is Able To Deliver Ultimate Network Experience To Users! Ultra M.2 32 Gb/S (Pcie Gen3 X4 & Sata3) The Pcie Gen3 X4 Ultra M.2 Interface Pushes Data Transfer Speeds Up To 32Gb/S. In Addition It Also Supports Sata3 6Gb/S M.2 Modules And Is Compatible With Asrocks U.2 Kit For Installing Some Of The Worlds Fastest U.2 Pcie Gen3 X4 Ssds. Dual Graphics Outputs Complete With Two Types Of Most Used Connectors! Packed With A Hdmi + Displayport Combo You Have More Graphics Output Options Now. Hdmi 4K @ 60Hz Supports The Most Recent Hdmi 4K 60Hz Graphics Output Specification. With The Larger Bandwidth And Increased Frame Rate The Motion On Your Screen Becomes More Fluid And Less Blurry. Water Pump Header This Is Not Only A Standard Cpu Fan Header But Also Supports Water Pumps! This Header Provides A Maximum Of 2A Power For Supporting The Most Popular Water Pumps. User Also Can Adjust The Voltage Of Water Pump To Get Higher Cooling Performance With Lower Noise. Specifications Unique Feature Asrock Super Alloy

• Premium 60A Power Choke
• 50A Dr.Mos
• Sapphire Black Pcb
• High Density Glass Fabric Pcb Intel 802.11Ac Wifi Asrock Ultra M.2 (Pcie Gen3x4 & Sata3) Asrock Full Spike Protection (For All Usb Audio Lan Ports) Asrock Live Update & App Shop Cpu Supports 10Th Gen Intel Core Processors And 11Th Gen Intel Core Processors (Lga1200) Digi Power Design 6 Power Phase Design Supports Intel Turbo Boost Max 3.0 Technology Chipset Intel H510 Memory Dual Channel Ddr4 Memory Technology 2 X Ddr4 Dimm Slots 11Th Gen Intel Core Processors Support Ddr4 3200 / 2933 / 2800 / 2666 / 2400 / 2133 Non-Ecc Un-Buffered Memory 10Th Gen Intel Core Processors Support Ddr4 2933 / 2800 / 2666 / 2400 / 2133 Non-Ecc Un-Buffered Memory Supports Ecc Udimm Memory Modules (Operate In Non-Ecc Mode) Max. Capacity Of System Memory: 64Gb Supports Intel Extreme Memory Profile (Xmp) 2.0 Bios 128Mb Ami Uefi Legal Bios With Multilingual Gui Support Acpi 6.0 Compliant Wake Up Events Smbios 2.7 Support Cpu Cpu Gt Vccsa Dram Vppm Vccin Aux Vccio Vccst Voltage Multi-Adjustment Graphics 11Th Gen Intel Core Processors Support Intel Xe Graphics Architecture (Gen 12). 10Th Gen Intel Core Processors Support Gen 9 Graphics Graphics Media & Compute: Microsoft Directx 12 Opengl 4.5 Intel Built In Visuals Intel Quick Sync Video Hybrid / Switchable Graphics Opencl 2.1 Display & Content Security: Rec. 2020 (Wide Color Gamut) Microsoft Playready 3.0 Uhd/Hdr Blu-Ray Disc Dual Graphics Output: Support Hdmi And Displayport 1.4 Ports By Independent Display Controllers Supports Hdmi 2.0 With Max. Resolution Up To 4K X 2K (4096X2160) @ 60Hz Supports Displayport 1.4 With Max. Resolution Up To 4K X 2K (4096X2304) @ 60Hz Supports Auto Lip Sync Deep Color (12Bpc) Xvycc And Hbr (High Bit Rate Audio) With Hdmi 2.0 Port (Compliant Hdmi Monitor Is Required) Supports Hdcp 2.3 With Hdmi 2.0 And Displayport 1.4 Ports Audio 7.1 Ch Hd Audio (Realtek Alc897 Audio Codec) Supports Surge Protection Lan Gigabit Lan 10/100/1000 Mb/S Giga Phy Intel I219v Supports Wake-On-Lan Supports Lightning/Esd Protection Supports Energy Efficient Ethernet 802.3Az Supports Pxe Wireless Lan Intel 802.11Ac Wifi Module Supports Ieee 802.11A/B/G/N/Ac Supports Dual-Band (2.4/5 Ghz) Supports High Speed Wireless Connections Up To 433Mbps Supports Bluetooth 4.2 / 3.0 + High Speed Class Ii Slots 11Th Gen Intel Core Processors 1 X Pci Express 4.0 X16 Slot 10Th Gen Intel Core Processors 1 X Pci Express 3.0 X16 Slot 1 X Vertical M.2 Socket (Key E) With The Bundled Wifi-802.11Ac Pcie Wifi Module (On The Rear I/O) Storage 4 X Sata3 6.0 Gb/S Connectors Support Intel Rapid Storage Technology 18 Ncq Ahci And Hot Plug 1 X Ultra M.2 Socket (M21) Supports M Key Type 2280 M.2 Sata3 6.0 Gb/S Module And M.2 Pci Express Module Up To Gen3 X4 (32 Gb/S) Connector 1 X Chassis Intrusion Header 1 X Addressable Led Header 1 X Cpu Fan Connector (4-Pin) 1 X Chassis Fan Connector (4-Pin) 1 X Chassis/Water Pump Fan Connector (4-Pin) (Smart Fan Speed Control) 1 X 24 Pin Atx Power Connector 1 X 8 Pin 12V Power Connector 1 X Front Panel Audio Connector 1 X Usb 2.0 Header (Supports 2 Usb 2.0 Ports) (Supports Esd Protection) 1 X Usb 3.2 Gen1 Header (Supports 2 Usb 3.2 Gen1 Ports) (Supports Esd Protection) Rear Panel I/O 2 X Antenna Ports 1 X Ps/2 Mouse/Keyboard Port 1 X Hdmi Port 1 X Displayport 1.4 2 X Usb 3.2 Gen1 Ports (Supports Esd Protection) 2 X Usb 2.0 Ports (Supports Esd Protection) 1 X Rj-45 Lan Port With Led (Act/Link Led And Speed Led) Hd Audio Jacks: Line In / Front Speaker / Microphone Software And Uefi Software
• Asrock Motherboard Utility (A-Tuning)
• Asrock Polychrome Sync
• Asrock Xfast Lan Uefi
• Asrock Ez Mode
• Asrock Full Hd Uefi
• Asrock My Favorites In Uefi
• Asrock Instant Flash
• Asrock Internet Flash Support Cd Drivers Utilities Antivirus Software (Trial Version) Google Chrome Browser And Toolbar Accessories Quick Installation Guide Support Cd I/O Shield 2 X Sata Data Cables 2 X Asrock Wifi 2.4/5 Ghz Antennas 1 X Screw For M.2 Socket Hardware Monitor Fan Tachometer: Cpu Chassis Chassis/Water Pump Fans Quiet Fan (Auto Adjust Chassis Fan Speed By Cpu Temperature): Cpu Chassis Chassis/Water Pump Fans Fan Multi-Speed Control: Cpu Chassis Chassis/Water Pump Fans Case Open Detection Voltage Monitoring: +12V +5V +3.3V Cpu Vcore Vccsa Form Factor Mini-Itx Form Factor: 6.7-In X 6.7-In 17.0 Cm X 17.0 Cm Solid Capacitor Design Os Microsoft Windows 10 64-Bit Certifications Fcc Ce Erp/Eup Ready (Erp/Eup Ready Power Supply Is Required)
