Asrock X570 Phantom Gaming 4 Socket AM4 ATX AMD X570

Supports Amd Am4 Socket Ryzen? 2000 And 3000 Series Processors10 Power Phase DesignSupports Ddr4 4066+ (Oc)2 Pcie 4.0 X16 2 Pcie 4.0 X1 1 M.2(Key E) For WifiAmd Quad Crossfirex? And Crossfirex?Graphics Output Options: Hdmi Displayport7.1 Ch Hd Audio (Realtek Alc1200 Audio Codec) Elna Audio Caps8 Sata3 1 Hyper M.2 (Pcie Gen4 X4 & Sata3) 1 Hyper M.2 (Pcie Gen4 X4)2 Usb 3.2 Gen2 (Rear Type-A) 10 Usb 3.2 Gen1 (4 Front 6 Rear)Intel? Gigabit LanAsrock Polychrome SyncSteel Slot With New-Gen Pci Express 4.0The Next Generation Pci Express 4.0 Is Capable Of Performing Twice The Speed Compared To Previous 3Rd Generation. Asrock?S Exclusive Steel Slot With Extra Anchor Points Are Revolutionary Added To Ensure Signal Stability And Also Making Sure Heavy Graphics Cards To Be Well-Installed In The Pci-E Slot Safely.Dual Hyper M.2 For SsdSupports The Next Generation Pci Express 4.0 M.2 Ssds It Is Capable Of Perform Twice The Speed Compared To Previous 3Rd Generation Giving A Lightning Fast Data Transferring Experience.10 Power Phase DesignFeaturing Sturdy Components And Completely Smooth Power Delivery To The Cpu. Plus It Offers Unmatched Overclocking Capabilities And Enhanced Performance With The Lowest Temperature For Advanced Gamers As Well.Post Status CheckerAn Easy Troubleshooting Tool That Shows The Cpu / Dram / Vga / Boot Operation Every Time You Start Up The System. Post Status Checker Is An Fast And Easy Way To Identify The Source Of The Problem.2 X Usb3.2 Gen2Delivering Data Transfer Rates Up To 10X Faster Than Usb 2.0 With Optimized Power Efficiency. Usb 3.2 Gen2 Technology Advances The Data Transfer Rate Up To 10Gb/S. Asrock Provides 2 X Usb 3.2 Gen2 Ports Onboard Allows You To Have A Stunning Data Transfer Experience.SpecificationsGaming ArmourMemory- 15? Gold Contact In Dimm SlotsVga Card- 15? Gold Contact In Vga Pcie Slot (Pcie1)Internet- Intel? LanCooling- Xxl Aluminum Alloy HeatsinkUnique FeaturesAsrock Usb 3.2 Gen2- Asrock Usb 3.2 Gen2 Type-A Ports (10 Gb/S)Asrock Super Alloy- Xxl Aluminum Alloy Heatsink- Premium 50A Power Choke- Sapphire Black Pcb- High Density Glass Fabric Pcb- 2Oz Copper PcbAsrock Steel Slot Gen4Asrock Hyper M.2 (Pcie Gen4x4 & Sata3)Asrock Post Status Checker (Psc)Asrock Full Spike Protection (For All Usb Audio Lan Ports)Asrock Live Update & App ShopCpuSupports Amd Am4 Socket Ryzen? 2000 And 3000 Series ProcessorsDigi Power Design10 Power Phase DesignChipsetAmd X570MemoryDual Channel Ddr4 Memory Technology4 X Ddr4 Dimm SlotsAmd Ryzen Series Cpus (Matisse) Support Ddr4 4066+(Oc) / 3466(Oc) / 3200/2933/2667/2400/2133 Ecc & Non-Ecc Un-Buffered MemoryAmd Ryzen Series Cpus (Pinnacle Ridge) Support Ddr4 3466+(Oc) / 3200(Oc) / 2933/2667/2400/2133 Ecc & Non-Ecc Un-Buffered MemoryAmd Ryzen Series Cpus (Picasso) Support Ddr4 3466+(Oc) / 3200(Oc) / 2933/2667/2400/2133 Non-Ecc Un-Buffered MemoryMax. Capacity Of System Memory: 128Gb15? Gold Contact In Dimm SlotsBios256Mb Ami Uefi Legal Bios With Gui SupportSupports “Plug And Play"Acpi 5.1 Compliance Wake Up EventsSupports JumperfreeSmbios 2.3 SupportCpu Cpu Vddcr_Soc Dram Vppm Prem Vdd_Cldo Perm Vddcr_Soc +1.8V Vddp Vddg Cpu Load-Line Calibration Cpu Vddcr_Soc Load-Line Calibration Voltage Multi-AdjustmentGraphicsIntegrated Amd Radeon? Vega Series Graphics In Ryzen Series ApuDirectx 12 Pixel Shader 5.0Shared Memory Default 2Gb. Max Shared Memory Supports Up To 16Gb.Dual Graphics Output: Support Hdmi And Displayport 1.2 Ports By Independent Display ControllersSupports Hdmi 2.0 With Max. Resolution Up To 4K X 2K (4096X2160) @ 60HzSupports Displayport 1.2 With Max. Resolution Up To 4K X 2K (4096X2160) @ 60HzSupports Auto Lip Sync Deep Color (12Bpc) Xvycc And Hbr (High Bit Rate Audio) With Hdmi 2.0 Ports (Compliant Hdmi Monitor Is Required)Supports Hdr (High Dynamic Range) With Hdmi 2.0Supports Hdcp 2.2 With Hdmi 2.0 And Displayport 1.2 PortsSupports 4K Ultra Hd (Uhd) Playback With Hdmi 2.0 And Displayport 1.2 PortsSupports Microsoft? PlayreadyAudio7.1 Ch Hd Audio With Content Protection (Realtek Alc1200 Audio Codec)Premium Blu-Ray Audio SupportSupports Surge ProtectionElna Audio CapsPcb Isolate ShieldingIndividual Pcb Layers For R/L Audio ChannelLanGigabit Lan 10/100/1000 Mb/SGiga Phy Intel? I211atSupports Wake-On-LanSupports Lightning/Esd ProtectionSupports Energy Efficient Ethernet 802.3AzSupports PxeSlotsAmd Ryzen Series Cpus (Matisse)- 2 X Pci Express 4.0 X16 Slots (Pcie1/Pcie3: Single At X16 (Pcie1); Dual At X16 (Pcie1) / X4 (Pcie3))Amd Ryzen Series Cpus (Pinnacle Ridge)- 2 X Pci Express 3.0 X16 Slots (Pcie1/Pcie3: Single At X16 (Pcie1); Dual At X16 (Pcie1) / X4 (Pcie3))Amd Ryzen Series Cpus (Picasso)- 2 X Pci Express 3.0 X16 Slots (Pcie1/Pcie3: Single At X8 (Pcie1); Dual At X8 (Pcie1) / X4 (Pcie3))2 X Pci Express 4.0 X1 SlotsSupports Amd Quad Crossfirex? And Crossfirex?1 X M.2 Socket (Key E) Supports Type 2230 Wifi/Bt Module15? Gold Contact In Vga Pcie Slot (Pcie1)Storage8 X Sata3 6.0 Gb/S Connectors Support Raid (Raid 0 Raid 1 And Raid 10) Ncq Ahci And Hot Plug1 X Hyper M.2 Socket (M2_1) Supports M Key Type 2230/2242/2260/2280/22110 M.2 Pci Express Module Up To Gen4x4 (64 Gb/S) (With Matisse) Or Gen3x4 (32 Gb/S) (With Pinnacle Ridge And Picasso)1 X Hyper M.2 Socket (M2_3) Supports M Key Type 2230/2242/2260/2280/22110 M.2 Sata3 6.0 Gb/S Module And M.2 Pci Express Module Up To Gen4x4 (64 Gb/S) (With Matisse) Or Gen3x4 (32 Gb/S) (With Pinnacle Ridge And Picasso)Connector1 X Com Port Header1 X Spi Tpm Header1 X Power Led And Speaker Header2 X Rgb Led Headers1 X Addressable Led Header1 X Cpu Fan Connector (4-Pin)1 X Cpu/Water Pump Fan Connector (4-Pin) (Smart Fan Speed Control)3 X Chassis/Water Pump Fan Connectors (4-Pin) (Smart Fan Speed Control)1 X 24 Pin Atx Power Connector1 X 8 Pin 12V Power Connector1 X Front Panel Audio Connector1 X Amd Led Fan Usb Header1 X Thunderbolt? Aic Connector (5-Pin) (Supports Asrock Thunderbolt? Aic Card Only)1 X Usb 2.0 Header (Supports 2 Usb 2.0 Ports) (Supports Esd Protection)2 X Usb 3.2 Gen1 Headers (Support 4 Usb 3.2 Gen1 Ports) (Supports Esd Protection)Rear Panel I/O3 X Antenna Ports (On I/O Panel Shield)1 X Ps/2 Mouse/Keyboard Port1 X Hdmi Port1 X Displayport 1.22 X Usb 3.2 Gen2 Type-A Ports (10 Gb/S) (Supports Esd Protection)6 X Usb 3.2 Gen1 Ports (Supports Esd Protection)1 X Rj-45 Lan Port With Led (Act/Link Led And Speed Led)Hd Audio Jacks: Line In / Front Speaker / MicrophoneSoftware And UefiSoftware- Asrock Polychrome Sync- Asrock Key Master- Asrock Xfast LanUefi- Asrock Full Hd Uefi- Asrock Instant Flash- Asrock Easy Raid InstallerSupport CdDrivers Utilities Antivirus Software (Trial Version) Google Chrome Browser And ToolbarAccessoriesQuick Installation Guide Support Cd I/O Shield2 X Sata Data Cables3 X Screws For M.2 SocketsHardware MonitoringTemperature Sensing: Cpu Cpu/Water Pump Chassis Chassis/Water Pump FansFan Tachometer: Cpu Cpu/Water Pump Chassis Chassis/Water Pump FansQuiet Fan (Auto Adjust Chassis Fan Speed By Cpu Temperature): Cpu Cpu/Water Pump Chassis Chassis/Water Pump FansFan Multi-Speed Control: Cpu Cpu/Water Pump Chassis Chassis/Water Pump FansVoltage Monitoring: +12V +5V +3.3V Cpu Vcore Cpu Vddcr_Soc Dram Prem Vddcr_Soc +1.8V VddpForm FactorAtx Form Factor: 12.0-In X 9.0-In 30.5 Cm X 22.9 CmSolid Capacitor Design2Oz Copper PcbOsMicrosoft? Windows? 10 64-Bit
