Asrock Z690 PG Riptide Intel Z690 LGA 1700 ATX

Gaming Design Reloaded Supports 12th Gen Intel® Core™ Processors (LGA1700) 13 Phase Dr.MOS Power Design Supports DDR4 4800MHz (OC) 1 PCIe 5.0 x16 1 PCIe 4.0 x16 3 PCIe 3.0 x1 1 M.2 Key-E for WiFi Graphics Output Options: HDMI Realtek ALC897 7.1 CH HD Audio Codec Nahimic Audio 8 SATA3 2 Hyper M.2 (PCIe Gen4 x4) 1 Ultra M.2 (PCIe Gen3 x4 & SATA3) 1 USB 3.2 Gen2x2 Rear Type-C 2 USB 3.2 Gen2 (Rear) 1 USB 3.2 Gen1 Front Type-C 6 USB 3.2 Gen1 (2 Rear 4 Front) Killer E3100 2.5G LAN Lightning Gaming Ports ASRock Graphics Card Holder Optimized VRM Design Dr. MOS Dr.MOS is the integrated power stage solution which is optimized for synchronous buck-set down voltage applications! Compared to traditional discrete MOSFETs it intelligently delivers higher current for each phase thus providing improved thermal result and superior performance. 13 Power Phase Design Featuring sturdy components and completely smooth power delivery to the CPU. Plus it offers unmatched overclocking capabilities and enhanced performance with the lowest temperature for advanced gamers as well. 6 Layer PCB The 6 Layer PCB provides stable signal traces and power shapes delivering lower temperature and higher energy efficiency for memory overclocking! Thus it’s able to support the latest memory modules with most extreme memory performance! 2oz Copper PCB 2 ounce copper inner layers that provide stable signal traces and power shapes! Delivering lower temperature and higher energy efficiency for overclocking. PCIe 5.0 + Surface-Mount Tech Compares to conventional DIP style PCIe slot the SMT type PCIe slot improves signal flow and maximize stability under high speed a key breakthrough to fully support the lighting speed of the latest PCIe 5.0 standard. The latest PCI Express 5.0 is capable to perform a breathtaking bandwidth of 128GBps ready to unleash the full potential of future high end graphic cards. Killer Ethernet E3100 The Killer E3100 2.5 Gbps Ethernet controller is designed specically for competitive gamers and performance-hungry users. The enhanced detection and prioritisation engine provides the ultimate networking experience for gaming and multimedia applications. Nahimic Audio Whether you are using headphones a headset external or internal speakers via USB Wi-Fi analog output or even HDMI Nahimic Audio offers you the most engaging listening experience vibrant and rich with details. Lightning Gaming Ports Aimed for die hard gamers and enthusiasts! Lightning Gaming Ports are sourced from two different controller interfaces that assist gamers in connecting the high speed mice/keyboard with the lower jitter and latency! Polychrome RGB In addition to the built-in RGB illumination it also features onboard RGB headers and an addressable RGB header that allow motherboard to be connected to compatible LED devices such as strip CPU fans coolers chassis and so on. Users may also synchronize RGB LED devices across the Polychrome RGB Sync-certified accessories to create their own unique lighting effects. *The addressable RGB LED header supports WS2812B addressable RGB LED strip (5V/Data/GND) with a maximum power rating of 3A (5V) a max of 80 LEDs and length within 2 meters. *The RGB LED header supports standard 5050 RGB LED strip (12V/G/R/B) with a maximum power rating of 3A (12V) and length within 2 meters. High Speed M.2 Solution This motherboard is capable of accomadating multiple M.2 storage devices one of which can support PCI Express 4.0 M.2 SSD it is capable of performing twice the speed compared to previous 3rd generation giving a lightning fast data transferring experience. EZ Setting Auto Driver Installer No need to worry about lack of disk drive! Asrock preinstall LAN driver to ensure that you are able to install all drivers needed in an easier way than using SCD. Install Auto Driver Installer Update drivers needed Done! BIOS Flashback Get the most convenient BIOS flashing with just a simple click. Users can easily achieve the latest BIOS support with a USB and power supply No CPU RAM or other components required.
