Asrock Z690M-ITX/ax Intel Z690 LGA 1700 mini ITX

Compact. Blazing Speed. Easy to Use. Supports 12th Gen Intel® Core™ Processors (LGA1700) 8 Phase Dr.MOS Power Design Supports DDR4 5000MHz (OC) 1 PCIe 5.0 x16 Graphics Output Options: HDMI DisplayPort Realtek ALC897 7.1 CH HD Audio Codec Nahimic Audio 4 SATA3 1 Hyper M.2 (PCIe Gen4 x4) 1 Hyper M.2 (PCIe Gen4 x4 & SATA3) 2 USB 3.2 Gen2x2 Type-C (1 Front 1 Rear) 4 USB Rear 3.2 Gen2 2 USB Front 3.2 Gen1 Dragon 2.5G LAN Intel® Gigabit LAN 802.11ax (WiFi 6E) + Bluetooth Optimised VRM Design Dr. MOS Dr.MOS is the integrated power stage solution which is optimised for synchronous buck-set down voltage applications! Compared to traditional discrete MOSFETs it intelligently delivers higher current for each phase thus providing improved thermal result and superior performance. 8 Power Phase Design Featuring sturdy components and completely smooth power delivery to the CPU. Plus it offers unmatched overclocking capabilities and enhanced performance with the lowest temperature for advanced gamers as well. 8 Layer PCB The 8 Layer PCB provides stable signal traces and power shapes delivering lower temperature and higher energy efficiency for memory overclocking! Thus it’s able to support the latest memory modules with most extreme memory performance! PCIe 5.0 + Surface-Mount Tech Compares to conventional DIP style PCIe slot the SMT type PCIe slot improves signal flow and maximize stability under high speed a key breakthrough to fully support the lighting speed of the latest PCIe 5.0 standard. The latest PCI Express 5.0 is capable to perform a breathtaking bandwidth of 128GBps ready to unleash the full potential of future high end graphic cards. Nahimic Audio Whether you are using headphones a headset external or internal speakers via USB Wi-Fi analog output or even HDMI Nahimic Audio offers you the most engaging listening experience vibrant and rich with details. Polychrome RGB This motherboard features onboard RGB headers and an addressable RGB header that allow motherboard to be connected to compatible LED devices such as strip CPU fans coolers chassis and so on. Users may also synchronize RGB LED devices across the Polychrome RGB Sync-certified accessories to create their own unique lighting effects *The addressable RGB LED header supports WS2812B addressable RGB LED strip (5V/Data/GND) with a maximum power rating of 3A (5V) a max of 80 LEDs and length within 2 meters. *The RGB LED header supports standard 5050 RGB LED strip (12V/G/R/B) with a maximum power rating of 3A (12V) and length within 2 meters. High Speed M.2 Solution This motherboard is capable of accomadating multiple M.2 storage devices one of which can support PCI Express 4.0 M.2 SSD it is capable of performing twice the speed compared to previous 3rd generation giving a lightning fast data transferring experience. Dragon 2.5 Gb/s LAN The intelligent 2.5Gb/s LAN platform is built for maximum networking performance for the demanding requirements of home networking content creators online gamers and high-quality streaming media. Boost networking performance up to 2.5X the bandwidth compared to the standard gigabit Ethernet you’ll enjoy the faster and uncompromised connectivity experience for gaming file transfers and backups. Wi-Fi 6E 802.11ax WiFi 6E technology has extended to the whole new 6GHz spectrum band providing more WiFi capability and giving an even better and faster internet traffic. In addition to deliver higher speeds the WiFi 6E also enhances the lower latency and supports service levels that are equivalent to 5G networks. USB 3.2 Gen2x2 20Gbps (Front + Rear) The latest USB 3.2 Gen2x2 Type-C delivers up to 20 Gbps data transfer rate which is 2x as fast as previous generation providing a blazing fast data transfer interface with reversible USB Type-C design that fits the connector either way. BIOS Flashback Get the most convenient BIOS flashing with just a simple click. Users can easily achieve the latest BIOS support with a USB and power supply No CPU RAM or other components required.
