Overview Asrock Z790 Pg Sonic An Officially Licensed Motherboard Featuring Sega?S Sonic The Hedgehog. A 16-Bit Spinning Ring Emblazons The Rear Io Cover While On The Rear Side You?Ll Even Catch A Glimpse Of Sonic Mid-Run. The Asrock Motherboard Is Co-Launched To Celebrate The Release Of Sega?S New Sonic Frontiers Game. Designed To Bring Back Epic Memories Of Catching Rings In Green Hill Zone The Motherboard Echoes Sonic?S Lightning Speed With Its Fast Blue And Silver Shards And Sonic Silhouette. Specifications Unique Feature Superb Productivity
- Pcie Gen5 (Graphics M.2)
- Dual Channel Ddr5 Rock-Solid Durability
- 14+1+1 Power Phase 50A Dr.Mos For Vcore+Gt
- Flexible Integrated I/O Shield Ultrafast Connectivity
- Killer 2.5G Lan
- Asrock Lightning Gaming Ports Ez Update
- Asrock Auto Driver Installer Ez Troubleshooter
- Asrock Post Status Checker Cpu
- Supports 13Th Gen & 12Th Gen Intel Core Processors (Lga1700)
- Supports Intel Hybrid Technology
- Supports Intel Turbo Boost Max 3.0 Technology
- Supports Intel Thermal Velocity Boost (Tvb)
- Supports Intel Adaptive Boost Technology (Abt) Chipset
- Intel Z790 Memory
- Dual Channel Ddr5 Memory Technology
- 4 X Ddr5 Dimm Slots
- Supports Ddr5 Non-Ecc Un-Buffered Memory Up To 6800+(Oc)
- Max. Capacity Of System Memory: 128Gb
- Supports Intel Extreme Memory Profile (Xmp) 3.0 Bios
- 128Mb Ami Uefi Legal Bios With Gui Support Graphics
- Intel Xe Graphics Architecture (Gen 12)
- 1 X Hdmi 2.1 Tmds Compatible Supports Hdcp 2.3 And Max. Resolution Up To 4K 60Hz
- 1 X Displayport 1.4 With Dsc (Compressed) Supports Hdcp 2.3 And Max. Resolution Up To 8K 60Hz / 5K 120Hz Audio
- 7.1 Ch Hd Audio (Realtek Alc897 Audio Codec)
- Nahimic Audio Lan
- 2.5 Gigabit Lan 10/100/1000/2500 Mb/S
- Killer E3100g
- Supports Killer Lan Software Slots Cpu:
- 1 X Pcie 5.0 X16 Slot (Pcie1) Supports X16 Mode Chipset:
- 1 X Pcie 4.0 X16 Slot (Pcie2) Supports X4 Mode
- 1 X Pcie 3.0 X1 Slot (Pcie3)
- 1 X M.2 Socket (Key E) Supports Type 2230 Wifi/Bt Pcie Wifi Module And Intel Cnvio/Cnvio2 (Integrated Wifi/Bt)
- Supports Amd Crossfire Storage Cpu:
- 1 X Hyper M.2 Socket (M2_1 Key M) Supports Type 2280 Pcie Gen4x4 (64 Gb/S) Mode
- 1 X Blazing M.2 Socket (M2_5 Key M) Supports Type 2280 Pcie Gen5x4 (128 Gb/S) Mode Chipset:
- 1 X Hyper M.2 Socket (M2_2 Key M) Supports Type 2260/2280 Pcie Gen4x4 (64 Gb/S) Mode
- 1 X Hyper M.2 Socket (M2_3 Key M) Supports Type 2260/2280 Pcie Gen4x4 (64 Gb/S) Mode
- 1 X Hyper M.2 Socket (M2_4 Key M) Supports Type 2260/2280 Pcie Gen4x4 (64 Gb/S) Mode
- 8 X Sata3 6.0 Gb/S Connectors Raid
- Supports Raid 0 Raid 1 Raid 5 And Raid 10 For Sata Storage Devices
- Supports Raid 0 Raid 1 And Raid 5 For M.2 Nvme Storage Devices Usb
- 1 X Usb 3.2 Gen2x2 Type-C (Front)
- 2 X Usb 3.2 Gen2 Type-A (Rear)
- 1 X Usb 3.2 Gen1 Type-C (Rear)
- 6 X Usb 3.2 Gen1 Type-A (4 Rear 2 Front)
- 6 X Usb 2.0 (2 Rear 4 Front) Connector
- 1 X Spi Tpm Header
- 1 X Power Led And Speaker Header
- 1 X Rgb Led Header
- 3 X Addressable Led Headers
- 1 X Cpu Fan Connector (4-Pin)
- 1 X Cpu/Water Pump Fan Connector (4-Pin) (Smart Fan Speed Control)
- 1 X Chassis Fan Connector (4-Pin) (Smart Fan Speed Control)
- 4 X Chassis/Water Pump Fan Connectors (4-Pin) (Smart Fan Speed Control)
- 1 X 24 Pin Atx Power Connector
- 2 X 8 Pin 12V Power Connectors (Hi-Density Power Connector)
- 1 X Front Panel Audio Connector
- 1 X Thunderbolt Aic Connector (5-Pin) (Supports Asrock Thunderbolt 4 Aic Card)
- 2 X Usb 2.0 Headers (Support 4 Usb 2.0 Ports)
- 1 X Usb 3.2 Gen1 Header (Supports 2 Usb 3.2 Gen1 Ports)
- 1 X Front Panel Type C Usb 3.2 Gen2x2 Header (20 Gb/S) Rear Panel I/O
- 2 X Antenna Mounting Points
- 1 X Hdmi Port
- 1 X Displayport 1.4
- 2 X Usb 3.2 Gen2 Type-A Ports (10 Gb/S)
- 1 X Usb 3.2 Gen1 Type-C Port
- 4 X Usb 3.2 Gen1 Type-A Ports (Usb32_56 Are Lightning Gaming Ports.)
- 2 X Usb 2.0 Ports
- 1 X Rj-45 Lan Port
- Hd Audio Jacks: Line In / Front Speaker / Microphone Software And Uefi Software
- Asrock Motherboard Utility (Phantom Gaming Tuning)
- Killer Control Center
- Asrock Polychrome Sync Uefi
- Asrock Ez Mode
- Asrock Full Hd Uefi
- Asrock My Favorites In Uefi
- Asrock Auto Driver Installer
- Asrock Instant Flash
- Asrock Easy Raid Installer Accessories
- 1 X User Manual
- 2 X Sata Data Cables
- 5 X Screws For M.2 Sockets Form Factor
- Atx Form Factor: 12.0-In X 9.6-In 30.5 Cm X 24.4 Cm
- 2Oz Copper Pcb Os
- Microsoft Windows 10 64-Bit / 11 64-Bit Certifications
- Fcc Ce
- Erp/Eup Ready (Erp/Eup Ready Power Supply Is Required)
