PRIME X670-PN/AASUS Prime series motherboards are expertly engineered to unleash the full potential of AMD Ryzen 7000-series processors. Boasting a robust power design comprehensive cooling solutions and intelligent tuning options PRIME X670-P provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features.N/AN/AFLEXIBILITYN/AComprehensive controls form the foundation of the ASUS PRIME series. The PRIME X670 motherboard packs flexible tools to tune every aspect of your system enabling performance tweaks to perfectly match the way you work to maximize productivity.N/AN/AIntelligent ControlN/AN/ACPU Performance BoostN/AAMD Precision Boost Overdrive(PBO) pushes the CPU current and voltage budget to opportunistically increase performance. By aggressively tuning the PBO parameters AMDs algorithm can leverage the motherboards robust power solution to ramp up performance even higher.N/AN/AAll-Around Energy EfficiencyN/AThe Power Saving function contains several settings can easily optimize power consumption and maximize energy savings. You can enable a CPU power limit darken Aura lighting and set the fan profile to a power saving mode. You can also toggle the Power Saver plan that is built into Microsoft Windows.N/AN/AFlexible Air- and Liquid-Cooling ControlsN/AASUS Fan Xpert 4 software provides comprehensive control over fans and all-in-one (AIO) coolers. Whether cooling with air or water an Auto-Tuning mode intelligently configures all parameters with a single click. Theres also an Extreme Quiet mode that reduces all fan speeds to below the default minimum to keep your system whisper-quiet when performing light tasks. Fans and AIO coolers can also be controlled via the UEFI BIOS.N/AN/APrecise Digital Power ControlN/AThe Digi+ voltage-regulator module (VRM) delivers real-time control over voltage droop automatically switching frequency and power-efficiency settings. It also allows you to fine-tune your CPU for ultimate stability and performance.N/AN/AAI Cooling llN/AAI Cooling II balances the thermals and acoustics of any build with a single click. A proprietary ASUS algorithm slashes unnecessary noise while running a quick stress test and then it monitors CPU temperatures to dynamically adjust fans to optimal speeds.N/AN/AUEFI BIOSN/AThe renowned ASUS UEFI BIOS provides everything you need to configure tweak and tune your system. It offers intelligently simplified options for PC DIY beginners as well as comprehensive features for seasoned veterans.N/AN/AAdvanced Tuning for Serious TweakersN/AAn intuitive Advanced mode offered via the UEFI lets you take complete control. A built-in search feature makes it easy to find options and various advanced functions let you intelligently make nuanced adjustments so you can dial in performance just the way you want.N/AN/ASearch FunctionN/AQuickly and easily find the option or setting you need.N/AN/AASUS User ProfileN/APort configuration settings between different BIOS versions or share them with friends.N/AN/AQuick and Simple SetupN/AEZ mode displays vital settings and stats and also offers guided wizards drag-and-drop functionality and one-click application of important settings all to help you get your rig up and running in no time.N/AN/AIntuitive Graphical Fan ControlN/AFine-tune individual fan settings simply by dragging a curve with the mouse.N/AN/AAura On/Off Mode (Stealth)N/AEasily enable or disable Aura RGB lighting or every onboard LED for a subdued aesthetic touch.N/AN/ACOOLINGN/APRIME X670 series is engineered with multiple onboard heatsinks and an array of hybrid fan headers to ensure your rig stays cool and stable under intense workloads.N/AN/AM.2 HeatsinkN/AAn M.2 heatsink takes care of the M.2 slot warding off throttling that can occur with M.2 storage during sustained transfers.N/AN/AVRM Heatsinks and High-quality Thermal PadsN/ATwo massive VRM heatsinks and high-quality thermal pads improve heat transfer from the MOSFETs and chokes for better cooling performance.N/AN/APassive Chipset HeatsinkN/AAn aluminum passive chipset heatsink ensures optimal cooling for more stable performance. The passive heatsink approach is more durable and longer-lasting avoiding dust and dirt build-up problems often encountered by conventional active heatsinks with dedicated fan designs.N/AN/ACooler by DesignN/APRIME X670 series features comprehensive cooling controls that are configurable via Fan Xpert 4 software or via the UEFI BIOS.N/AN/AMultiple Temperature SourcesN/AEach header can dynamically reference four thermal sensors. Fan Xpert 4 allows you to map the temperature of supported ASUS graphics cards to optimize cooling for GPU- and CPU-intensive tasks.N/AN/AAIO Pump HeaderN/AA dedicated PWM/DC header for self-contained water-cooling setups.N/AN/ASmart ProtectionN/AA dedicated integrated circuit protects each fan header from overheating and overcurrent.N/AN/A4-Pin PWM/DC FanN/AEach onboard header supports auto-detection of PWM or DC fans.N/AN/APERFORMANCEN/AThe PRIME X670 series is built to handle the high core counts and bandwidth demands of AMD processors. ASUS X670 motherboard provides all the fundamentals to boost daily productivity so your system will be ready for action with stable power intuitive cooling and flexible data transfer options.N/AN/ARobust Power DesignN/AStable power is essential to extract every last bit of performance out of AMD processors. The PRIME X670-P is geared to cater to the demands of these high-core-count CPUs.N/AN/AProCool ConnectorsN/AProprietary connectors augment the motherboard’s link to the PSU with 4 pin+8 pin connectors that pass 12 volts of power directly to the processors. Each jack features solid pins that can handle more current than hollow-pin connectors.N/AN/A12+2 DrMOS Power StagesN/A12+2 DrMOS power stages combine high-side and low-side MOSFETS and drivers into packages rated for 60 amperes each delivering power efficiency stability and performance to current and future AMD processors.N/AN/ASix-Layer PCB DesignN/AMultiple PCB layers optimize heat management for critical components providing more headroom to push CPUs beyond stock speeds.N/AN/AStack Cool 3+N/A2-ounce copper layers draw heat away from critical components to keep them at their optimal operating temperatures and provide more headroom to push CPUs beyond stock speeds.N/AN/ADDR5 Performance EnhancementN/AComprehensive memory tuning options are the cornerstone of PRIME motherboards. With the PRIME X670-P you can extract all of the potential out of your DDR5 modules whether they’re from an extreme-speed kit or an entry-level set that would otherwise be locked.N/AN/AFor entry-level modules without EXPOTM memory support weve got you covered.N/AN/AFor those who want to fly past stock DDR5 speeds the PRIME X670-P is primed and ready for enthusiast-grade kits courtesy of vast AMD Extended Profiles for Overclocking (EXPOTM) support. Seasoned veterans can further tweak performance via the extensive array of settings in the UEFI.N/AN/AASUS OptiMem IIN/ARevisions to the motherboards trace routing provide the latest Intel processors with unrestricted access to memory bandwidth. ASUS OptiMem II technology carefully maps memory signal pathways across different PCB layers to reduce vias and adds shielding zones that significantly reduce crosstalk.N/AN/ABenefits of ASUS OptiMem II:N/AN/A- Improved memory stability and compatibilityN/A- Allows lower memory latencies at equivalent voltagesN/A- Improved memory frequency marginN/AN/AMotherboards with OptiMem II technology were tested with Synopsys HSPICE simulation softwareN/AN/AStorageN/APCIe 5.0 M.2 SupportN/APRIME X670-P offers a total of three M.2 slots the first one supports data-transfer speeds of up to 128Gbps via PCIe 5.0 enabling quicker boot-up and app load times with OS or application drives.N/AN/AActual transmission speeds will be lower than the theoretical maximum speed.N/AN/AConnectivityN/AN/APCIe 4.0 SlotN/APrime X670 motherboards offer PCIe 4.0 Slot connectivity for the latest GPUs. The wide bandwidth and superfast transmission speeds allow you to create feature-rich builds that can handle high loads effortlessly.N/AN/AUSB 3.2 Gen 2x2 Type-CN/AA batch of USB ports support high-end rigs loaded with peripherals including a rear USB Type-C connector with ultrafast USB 3.2 Gen 2x2 for transmission speeds of up to 20Gbps.N/AN/AFront USB Type-CN/AA full complement of USB ports support high-end rigs loaded with peripherals including a front-panel USB 3.2 Gen 1 Type-C connector that provides data transfer speeds of up to 5Gbps.N/AN/AUSB4 SupportN/APRIME X670 motherboard features USB4 support via a Thunderbolt (USB4) header. With an ASUS add-on card PRIME motherboards can enable bi-directional speeds of up to 40 Gbps on a single cable while providing power to fast-charge device. Additionally this card has a daisy-chain function for multi-screen connection and supports up to dual displays with 4K resolution.N/A*ASUS add-on card is sold separately.N/AN/ARealtek 2.5 Gb EthernetN/ARealtek 2.5 Gb Ethernet reduces CPU overhead and offers exceptionally high TCP and UDP throughput for faster smoother data transfers.N/AN/ALANGuardN/AASUS LANGuard is a hardware-level network protection feature that integrates advanced signal-coupling technology and premium anti-EMI surface-mounted capacitors to improve throughput and ensure a more reliable connection.N/AN/ACUSTOMIZATIONN/AThe PRIME X670 series adds the nuanced details that improve every experience from exclusive codecs that provide pristine audio quality to intuitive RGB lighting controls that let you customize your system to create a uniquely personal look.N/AN/AOutstanding AudioN/ACombined onboard features deliver elevated audioN/AIntelligent design and premium hardware create audio quality unlike anything youve ever experienced.N/AN/AAudio ShieldingN/AAudio shielding ensures precision analog/digital separation and greatly reduced multi-lateral interference.N/AN/ADedicated Audio PCB LayersN/ASeparate layers for left and right tracks ensures both channels deliver consistent equal quality.N/AN/APremium Audio CapacitorsN/AProvides warm natural and immersive sound with exceptional clarity and fidelity.N/AN/APersonalizationN/AN/AAura SyncN/AOutshine the CompetitionN/AA well-tuned enthusiast system deserves a matching aesthetic. ASUS Aura offers full RGB lighting control with a variety of functional presets for the built-in RGB LEDs as well as strips and devices connected to the onboard RGB headers and it can all be synced with an ever-growing portfolio of Aura-capable hardware.N/AN/AAddressable Gen 2 HeadersN/AThree addressable Gen 2 headers are capable of detecting the number of LEDs on second-gen addressable RGB devices allowing the software to automatically tailor lighting effects to specific devices. The new headers also offer backward-compatibility with existing Aura RGB gear.N/AN/AArmoury CrateN/AWithin a single intuitive interface Armoury Crate offers easily customized Aura Sync RGB settings for every compatible device in your arsenal plus controls for an ever-growing family of ASUS products including keyboard and mouse preferences. Armoury Crate also integrates product registration and a news feed so that you never miss updates of interest to the ASUS community.N/AN/ADIY FriendlyN/AN/AQ-LED CoreN/AThe Q-LED Core display produces light patterns by power LED during the Power-On Self-Test (POST) that can help users troubleshoot potential issues.N/AN/AQ-LatchN/AThe innovative Q-Latch makes it easy to install or remove an M.2 SSD without the need for specific tools. The design employs a simple locking mechanism to secure the drive and neatly eliminate traditional screws.N/AN/ABIOS FlashBackN/ABIOS FlashBack is the simplest and safest (UEFI) BIOS update method. Simply drop the (UEFI) BIOS file onto a FAT32 formatted USB stick plug it into the USB BIOS FlashBack port and press the button. Updates can even be performed without a memory or a CPU installed.N/AN/ASafeSlot Core+N/APCIe 4.0 is 2x faster than PCIe 3.0 so we adapted our SMT manufacturing process for the faster SafeSlot Core+ to ensure the highest data speeds. SafeSlot Core+ is a reinforced metal sheath added to a PCIe slot to keep a card firmly installed.N/AN/AOvervoltage ProtectionN/AWorld-class circuit-protecting power designN/AAn exclusive circuit design with built-in voltage regulators to protect your motherboard from damage caused by unexpected high-level voltages from unstable or inferior power supplies.N/AN/ATHIS CHANGES EVERYTHING.N/AFROM THIS NEW PLATFORM YOU CAN SEE THE FUTUREN/ABuild your next rig with an AMD Ryzen 7000 Series processor and PRIME X670-P to experience advanced performance. With up to 16 Zen 4 cores and 32 threads boost clocks of up to 5.7GHz and 80MB cache the AMD Ryzen 7000 Series keeps you ahead of the game.1N/AN/AYoull also gain access to new features for gamers with AMD Socket AM5 from the speed of DDR5 memory to the increased bandwidth of PCIe 5.0. AMD Ryzen 7000 Series processors and AMD socket AM5 motherboards are unlocked for overclocking to personalize your experience. Gain even more performance when you overclock your DDR5 memory with AMD EXPO technology.2
