Tinker Board 2N/AAn Arm-based Single Board Computer (SBC) uses Arm big.LITTLE technology’s 64-bits processor offers enhanced computing performance with low power consumption.N/AN/AEnhanced CPU performanceN/APowered by Arm 6-core system on a chip (SoC) with the new 64-bit Armv8 architecture the Rockchip RK3399 Tinker Board 2 offers significantly improved performance versus compared to other popular SBC boards. It also features Arm big.LITTLE technology which is a heterogeneous processing architecture that pairs two very different processors together in a single SoC. The big.LITTLE software automates task allocation ensuring the right CPU core for each process. The upshot is that Tinker Board 2 delivers up to nearly twice the performance of the original Tinker Board and is significantly faster than many competing SBCs.N/AN/AEnhanced GPU performanceN/AThe GPU bundled with Tinker board 2 is Mali-T860 a multi - core GPU that is the highest performance model built on Arm’s Midgard architecture. Specifically Mali-T860 is designed for complex graphics use cases and offers full support for OpenGL ES 3.0/3.1 OpenVG 1.1 OpenCL and other frameworks for next-generation and legacy 2D/3D graphics applications. Compared to the original Tinker Board Tinker Board 2’s Mali-T860 GPU accelerates graphics performance by up to 28%.N/AN/ADUAL-DISPLAY SUPPORTN/ATinker Board 2 supports dual displays at up to 4K UHD resolution so it’s equipped for compelling visual output. It also has three popular display interfaces built in including HDMI DisplayPort over USB-C and DSI for superb flexibility.N/AN/AWI-FI AND BLUETOOTHN/ANext-level 802.11ac Wi-Fi with 2x2 dual-band 2.4/5 GHz antennas deliver transfer speeds that are up to 10X faster than previous Wi-Fi standards. Tinker Board 2 also has the latest Bluetooth 5.0 technology built in so you’ll enjoy speeds that are up to 2X transmit speeds and with up to 4X-greater range. Integrated Bluetooth also opens up the convenience and freedom of wireless connectivity with a wide range of devices including speakers headphones and game controllers.N/AN/ARICH CONNECTIVITY: USB 3.2 GEN 1N/ATinker Board 2 has three USB 3.2 Gen 1 Type-A ports and one USB 3.2 Gen 1 Type-C (USB-C) port for data-transfer speeds that are up to 10X faster than USB 2.0 - plus the convenience of any-way-up connectivity. Tinker Board 2’s USB 3.2 Type-A ports delivers up to 0.9A of power while the USB-C connector supplied up to 1.5A for charging speeds that are considerably faster than older USB 2.0 ports. The USB 3.2 Gen 1 Type-C supports OTG functionality and DisplayPort Alt Mode for DP alt mode to connection of an external displays.N/AN/AEXPANDABILITY FOR EMBEDDED SOLUTIONSN/AN/ARTC battery headerN/AEnables real-time clock (RTC) functions for scheduling of startup and shutdown timers and other related functions. Also enables ability for the system clock to keep time when mains power is lost or otherwise unavailableN/AN/ASD card slot (rear side)N/A- Simple push-pull operationN/A- Spring-free design prevents accidental ejection for greater reliabilityN/AN/AFan connectorN/AIntegrated 2-pin header provides easy upgradeability for advanced cooling needsN/AN/ACOMPREHENSIVE PROTECTIONN/AN/AShort-circuit damage preventionN/AOnboard power IC and polyswitch prevent overcurrent and short-circuit damage protecting the lifespan both of Tinker Board 2 and connected devicesN/AN/AElectrostatic discharge protectionN/AASUS ESD Guards prolong the life of components while preventing damage from electrostatic discharge providing protection for up to +/- 15kV of air discharge and +/- 8kV of contact dischargeN/AN/AOvervoltage protection World-class circuit-protecting power designN/AAn exclusive circuit design with built-in voltage regulators protects Tinker Board 2 from damage caused by unexpected high-level voltages from unstable or inferior power supplies.N/AN/AEASY SETUP TOOLN/ATinker Board 2 includes a flexible setup tool to tune every aspect of your system enabling you to tweak performance settings to perfectly match the way you work. Initial configuration follows just three simple steps:N/AN/AStep 1: Select the CPU Governor mode.N/AN/AStep 2: Set the maximum and minimum frequencies for the CPU and GPU.N/AN/AStep 3: Use the Monitor panel to confirm that the operating system is following the settings configured in Steps 1 and 2.N/AN/AIT MANAGEMENT SOFTWAREN/AASUS IoT Cloud ConsoleN/AAICC is a unified platform for managing and analyzing big data collected by IoT devices running different operating systems.N/A- Quick troubleshootingN/A- Remote restart or updatesN/A- Dashboard and analysisN/AN/AASUS Industrial Android FOTAN/ATinker Board 2 supports firmware over-the-air (FOTA) roll-out enabling embedded systems developed using the board to be updated remotely with the latest Android firmware operating system and drivers.N/A- Worldwide content-delivery networkN/A- Easy deployment and maintenanceN/A- FOTA progress reportN/AN/ASUPPORT FOR ANDROID 10N/ATinker Board 2 is engineered to run Android 10 opening your tinkering world to a raft of exciting and interesting features that aren’t unavailable on some competing SBCs.N/AN/AThese include:N/AN/APerformanceN/ABetter 3D computing performance at lower CPU loads and with reduced power consumption. Android 10 also provide flexible APIs for easy management of IoT devices connected to the same wireless network.N/AN/AReady for AIN/AAndroid Neural Networks API (NNAPI) updated to version 1.2 with support for more operations making Tinker Board 2 suitable for computationally intensive machine-learning operations.N/AN/ASecurityN/AAdiantum encryption is now up to 5X more efficient than AES encryption. Specifically with TLS 1.3 the transmission process is more secure and the connection performance is also improved.
