ASUS TUF GAMING Z690-PLUS WIFI D4 Intel Z690 LGA 1700 ATX

Durable. Stable. Reliable.N/AASUS TUF GAMING Z690-PLUS WIFI D4 takes all the essential elements of the latest Intel processors and combines them with game-ready features and proven durability. Engineered with military-grade components an upgraded power solution and a comprehensive cooling system this motherboard offers rock-solid and stable performance for marathon gaming. Aesthetically TUF GAMING Z690-PLUS WIFI D4 sports the new TUF Gaming logo and incorporates simple geometric design elements to reflect the dependability and stability that defines the TUF Gaming series.N/AN/ARock-Solid PerformanceN/AWith upgraded power delivery and comprehensive cooling options to drive the 12th Gen Intel Core processors plus support for faster memory and storage TUF GAMING Z690 motherboards are the perfect foundation for your next high-core-count battle rig.N/AN/APower DesignN/AN/ADrMOSN/AThe onboard VRMs feature 14+1 DrMOS power stages that combine high-side and low-side MOSFETs and drivers into a single package delivering the power and efficiency that 12th Gen Intel Core processors demand.The power stages are each rated to handle 80 amperes to provide stable performance for current and future Intel processors.N/AN/ASix-Layer PCB DesignN/AMultiple PCB layers optimize heat management for critical components providing more headroom to push CPUs beyond stock speeds.N/AN/AProCool ConnectorsN/AEnhanced EATX 8-Pin and 4-Pin ConnectorsN/A Provide extreme durabilityN/A Prevent hotspots and connector failureN/AN/ACompared to traditional power inputs ASUS ProCool connectors are built to tight specifications to ensure full contact with PSU power cables. The resulting lower impedance helps prevent hotspots and connector failure.N/AN/ATUF ChokesN/ACertified military-grade TUF chokes deliver rock-solid power to the CPU improving system stability.N/AN/ATUF CapacitorsN/AProprietary capacitors provide up to 20% wider temperature tolerance and five times longer lifespan.N/AN/ADigi+ VRMN/AThe integrated Digi+ voltage-regulator module (VRM) is one of the finest in the industry optimized for ultra-smooth and ultra-clean power delivery to the CPU at all times.N/AN/ACOOLINGN/AN/ACooler by designN/A1. Enlarged VRM heatsinkN/AThe extensive surface area of the massive heatsink covers the VRMs and chokes to improve heat dissipation.N/AN/A2. Enlarged PCH heatsinkN/AAn expanded surface area for the chipset cooler maximizes performance and heat dissipation.N/AN/A3. Three M.2 slots with heatsinksN/AThree out of four M.2 slots have dedicated heatsinks keeping M.2 SSDs at optimal operating temperatures to ensure consistent performance and reliability.N/AN/AComprehensive Fan ControlsN/ATUF GAMING Z690 motherboards feature comprehensive fan controls that can be configured via the Fan Xpert 4 utility or the award-winning ASUS UEFI BIOS.N/AN/AEach header can be set to monitor and react to three user-configurable thermal sensors for workload-based cooling and all settings can be easily managed by Fan Xpert 4 or via the UEFI.N/AN/AAn integrated AIO system enables full control of PWM or DC water pumps making it perfect for custom or self-contained cooling setups.N/AN/AAll onboard chassis fan headers support auto-detection of PWM or DC fans.N/AN/A dedicated integrated circuit protects each fan header from excess heat and electrical currents.N/AN/AMEMORY & STORAGEN/AN/ADRAM Overclocking PerformanceN/ADDR4 OC 5333N/AImprovements to trace routing design provide the latest Intel processors with enhanced access to memory bandwidth. ASUS OptiMem II technology carefully maps memory signal pathways across different PCB layers to reduce path distance and it adds shielding zones that significantly reduce crosstalk.N/AN/AFour PCIe 4.0 M.2N/AThe four PCIe 4.0 M.2 slots support up to two 22110 devices and also provide NVMe SSD RAID support for incredible performance potential. Create a RAID configuration with up to four PCIe 4.0 storage devices to enjoy the fastest data transfer speeds.N/AN/ACONNECTIVITYN/AN/APCIe 5.0N/AThe 12th Gen Intel processors bring PCIe 5.0 support to the market. PCIe 5.0 offers twice the data transfer speed of PCIe 4.0 making it robust enough to handle new data-heavy tasks. PCIe 5.0 also brings other benefits such as electrical changes to improve signal integrity backward-compatible CEM connectors for add-in cards and backward compatibility with previous versions of PCI ExpressN/AN/AFront USB PortN/AA full complement of USB ports support high-end rigs loaded with peripherals including a front-panel USB 3.2 Gen 2 Type-C connector that provides data transfer speeds of up to 10 Gbps.N/AN/AUSB 3.2 Gen 2x2 Type-CN/AExtensive USB support ensures connections to a wide array of peripherals. TUF GAMING Z690-PLUS WIFI D4 includes a USB 3.2 Gen 2x2 Type-C port on the rear I/O panel that delivers increased bandwidth and transmission speeds of up to 20 Gbps.N/AN/AThunderbolt 4 SupportN/ATUF GAMING Z690 series features Thunderbolt 4 support via an on-board header. With an Intel-certified ASUS ThunderboltEX 4 add-on card* TUF GAMING Z690-PLUS WIFI D4 can also enable bi-directional speeds of up to 40 Gbps on a single cable. Additionally this card has a daisy-chain function for multi-screen connection and supports up to an 8K resolution display. It can also provide up to 100 watts of power to fast-charge devices.N/A* ASUS ThunderboltEX 4 add-on card is sold separately.N/AN/AEasy PC DIYN/ATUF GAMING motherboards are designed to be easy to set up and configure just the way you want even for first-time builders. The TUF GAMING Alliance ecosystem makes selecting compatible parts easy while Armoury Crate software provides Fan Xpert 4 and hardware information and offers full full control of Two-Way AI Noise Cancellation RGB lighting and peripheral settings. The TUF GAMING platform gives you the arsenal you need to build and optimize your dream gaming rig without unnecessary complexity.N/AN/ABuild with ConfidenceN/ATUF GAMING Alliance is a collaboration between ASUS and trusted PC component brands to ensure compatibility across a wide range of parts such as PC cases power supplies CPU coolers memory kits and more. With new partnerships and components being added regularly the TUF Gaming Alliance will continue to grow even stronger.N/AN/ASafeSlot & SafeDIMMN/APCIe 5.0 is 2x faster than PCIe 4.0 so we adapted our SMT manufacturing process for the faster SafeSlot to ensure the highest data speeds. SafeSlot is a reinforced metal sheath added to a PCIe slot to keep a card firmly installed. Meanwhile strong ASUS SafeDIMM sheathes support and protect memory modules on select ASUS motherboards empowering you to insert your modules with speed accuracy and confidence.N/AN/AESD GuardsN/AESD Guards prolong the life of components while preventing damage from electrostatic discharge providing protection for up to +/- 10 kV of air discharge and +/- 6 kV of contact discharge greatly surpassing the respective industry standards of +/- 6 kV and +/- 4 kV. Surface-mounted TVS diodes in a dual in-line package help protect your PC from voltage spikes.N/AN/ATUF LANGuardN/ATUF LANGuard is a military-grade innovation that integrates advanced signal-coupling technology and premium surface-mounted capacitors to improve throughput protecting the motherboard from lightning strikes and static electricity.N/AN/ADRAM Overvoltage ProtectionN/AOnboard resettable fuses prevent overcurrent and short-circuit damage. This extends beyond I/O ports to DRAM to safeguard the lifespan of your system and connected devices.N/AN/AStainless Steel Back I/O PanelN/ATUF GAMING motherboards have a corrosion-resistant stainless steel back I/O panel bonded with chromium oxide to provide a lifespan thats three times longer than traditional panels. With this protective feature TUF GAMING motherboards passed 72-hour salt fog testing while other brands only passed 24-hour testing.N/AN/AEASY CONFIGURATIONN/AN/AM.2 Q-LatchN/AThe innovative Q-Latch makes it easy to install or remove an M.2 SSD without the need for specific tools. The design employs a simple locking mechanism to secure the M.2 SSD neatly eliminating the need for screws.N/AN/AQ-LEDN/AThe on-board Q-LED troubleshooting lights give PC builders a quick indicator to confirm that key components CPU RAM graphics card storage devices are functioning normally during startup.N/AN/AArmoury CrateN/AArmoury Crate is exclusive ASUS software that gives you centralized control of supported gaming products. From a single intuitive interface Armoury Crate lets you easily customize RGB lighting and effects for every compatible device in your arsenal and synchronize them with Aura Sync for unied system lighting effects. It also provides hardware information and control of settings for a select and growing number of products including keyboard and mouse preferences Fan Xpert 4 and Two-Way AI Noise Cancelation making it easier to tune the look and feel of your system. Armoury Crate even features dedicated product registration and news sections to help you stay in touch with the gaming community.N/AN/AImmersive GamingN/ATUF GAMING Z690 motherboards provide a high-performance gaming package with a long list of features to improve your experiences including ultrafast networking for smoother online gameplay pristine audio with positional cues for FPS gaming and onboard RGB lighting that syncs with attached accessories to help you create a personalized gaming atmosphere.N/AN/ANetworkingN/AN/AIntel WiFi 6N/AThe Intel WiFi 6 module is compatible with the 802.11ax standard and pushes theoretical peak bandwidth up to an incredible 2.4 Gbps. Perhaps more importantly for power users it’s optimized for more efficient operation on crowded networks with a lot of competing traffic. Pair your motherboard with ASUS WiFi 6 routers to fully experience the networking potential of WiFi 6. The WiFi antenna designs with four-way positioning that enables better signal reception and a magnetic base to secure the antenna on the top or side of the PC case.N/AN/AIntel 2.5 Gb EthernetN/AOnboard 2.5 Gb Ethernet gives your wired connection a boost with speeds that are up to 2.5x faster than standard Ethernet connections. This translates to incredibly fast file transfers low-lag online gaming and high-res video streaming.N/AN/ATwo-Way AI Noise CancelationN/AThis powerful ASUS-exclusive utility leverages a massive deep-learning database to reduce background noise from the microphone* and incoming audio while preserving voices. Distracting keyboard clatter mouse clicks and other ambient noises are removed so you can hear and be heard with perfect clarity while gaming or during calls.N/A*An audio splitter (3.5 mm audio jack Y-cable) is necessary when using a 3.5 mm headset.N/AN/AGaming AudioN/AN/ARealtek 7.1 Surround SoundN/A1.TUF Gaming audio chip protectionN/AEnhanced electrical shielding preserves the integrity of audio signals to ensure the best quality.N/AN/A2. High-definition audioN/APremium audio capacitors provide warm natural and immersive sound.N/AN/A3. Audio shieldingN/AOur specialized audio path design separates analog and digital signal domains to significantly reduce multi-lateral interference.N/AN/ADTS Audio ProcessingN/ADTS Audio Processing enhances gaming headset and speaker audio experiences by reducing distortion and by providing deeper bass so games movies and music sound better. It also allows you to customize audio settings.N/AN/AOutshine the CompetitionN/AA well-tuned system deserves a matching aesthetic. TUF Gaming Z690 series features edge lighting to enhance its rugged look and now the PCH heatsink gets RGB lighting to take the style even further. ASUS Aura offers full RGB control with a variety of functional presets for built-in LEDs as well as third-party strips you can connect to onboard RGB headers. And it can all be synced with an ever-growing portfolio of Aura-capable hardware.N/AN/AAddressable Gen 2 RGB HeaderN/AThe addressable Gen 2 RGB header is now capable of detecting the number of LEDs on second-gen addressable RGB devices allowing the software to automatically tailor lighting effects to specific devices. The new header also offers backward-compatibility with existing addressable RGB gear.
