Features
- Local and Remote Units connect at distances up to 300 m using Cat 5e cable
- Dual console operation - control your system from both the local and remote USB keyboard monitor and mouse consoles
- Deskew Function - automatically synchronizes the time delay of RGB signals to compensate for distance
- Built-in ASIC for greater reliability and compatibility
- Auto Signal Compensation (ASC)
- RS-232 serial ports - allow you to connect to a serial terminal or serial devices such as touchscreens and barcode scanners
- Sun/Mac keyboard support and emulation*
- Audio Enabled - supports stereo speakers and microphone
- USB overcurrent detection and prevention
- Pushbutton operating mode selection (Local Unit only) - select between Local and Auto operating modes with the press of a single button
- Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV) and 2KV surge protection
- High resolution video - up to 1920 x 1200@ 60Hz (150 m); 1280 x 1024@ 60Hz (300 m)
- Superior Audio - no loss in audio quality at 300 m
- Spports Wide Screen formats
- Supports VGA SVGA SXGA (1280 x 1024) UXGA (1600 x 1200) WUXGA (1920 x 1200) and multisync monitors; local monitor supports DDC; DDC2; DDC2B
- Hot pluggable
- Rack mountable
- Easy to install - no software required - connecting cables to the devices is all it takes Package Content
- 1x CE770L USB KVM Extender (Local Unit);
- 1x CE770RQ USB KVM Extender (Remote Unit);
- 1x USB KVM Cable (1.8m);
- 2x Power Adapter;
- 1x Rack Mount Kits;
- 2x Grounding Wires;
- 1x User Manual;
- 1x Quick Start Guide.
