Features
- Integrated KVM console with 17" LCD monitor in a Slideaway housing.
- Available with or without Fingerprint Identification Reader.
- Space saving technology - up to two consoles (one bus) control up to 16 computers.
- Daisy-chain up to 31 additional units - control up to 512 computers from a single console (With compatible KVM Swithces: ACS1208A ACS1216A CS1708ACS1716A).
- Dual Interface - supports computers and console with PS/2 or USB keyboards and mice.
- LCD module USB port allows each computer to access USB peripherals.
- LCD module rotates up to 115 degrees for a more comfortable viewing angle.
- Multiplatform support - Windows 2000/XP/Vista Linux Mac and Sun.
- Supports multimedia USB keyboards for PC Mac and Sun.
- Auto PS/2 and USB interface detection.
- Keyboard and mouse emulation (PS/2 and USB) for smooth switching and simultaneous booting of multiple computers even when the console focus is elsewhere.
- Supports external USB mouse.
- Superior video quality - supports resolutions up to 1280 x 1024 @ 75 Hz.
- No software required - convenient computer selection via front panel pushbuttons hotkeys and multilingual on-screen display (OSD) menus.
- Auto-senses station’s position on daisy-chained installations; no need for manual dip switch setting; front panel led indicates station’s position.
- Port names automatically reconfigured when station sequence is changed.
- Two level password security - only authorized users can view and control computers.
- Supports one administrator and four user accounts with separate profiles.
- Auto Scan mode enables continuous monitoring of user-selected computers.
- Broadcast support - commands from the keyboard can be broadcast to all available computers on the installation.
- Hot pluggable - add or remove computers without having to power down the switch.
- Beeper on/off via hotkey and OSD.
- Firmware upgrades to all the chained KVM switches at the same time via the daisy-chain cable. Package Contents
- 1x CL5716 LCD KVM Switch with standard Rack Mount Kit
- 1x 2L-5202P PS/2 KVM Cable
- 1x 2L-5202U USB KVM Cable
- 1x LIN5-27X6-U21G 5-in-1 USB / PS/2 Console Cable
- 1x Firmware Upgrade Cable
- 1x 1ADP-0005-005G Power Cord (AC Power Models)
- 1x User Instructions
