Convenient computer selection via front panel pushbuttons hotkeys and multilingual on-screen display (OSD) menus
Up to 32 concurrent logins
Multilanguage web UI support featuring a tree-structured local and remote OSD
Adjustable video quality for flexible adaptation to diverse network environments
Auto Scan feature for monitoring user-selected computers
Broadcast mode; operations simultaneously performed on all selected computers (software installation system-wide shutdown etc.).
Firmware upgradable
Backup and restore configuration and user account settings
Event logging
Enable/disable browser access
IPv6 capable
Ease-to-Use Interface
Browser-based and AP GUIs together with a menu-driven OSD for the local console provide a powerful intuitive user-friendly multilanguage interface to minimize user training time and increase productivity
Multiplatform client support (windows Mac OS X Linux Sun)
Multibrowser support (IE Mozilla Firefox Safari Opera Netscape)
Port names automatically reconfigured when station sequence is changed
Panel array mode enables user to monitor multiple servers from single screen at the same time - each selected server’s video output appears in a separate panel - users can easily select the number of panels to view
Windows client and Java client software support; Java client works with all operating systems
Advanced Security
Secure keyboard/mouse/video transmission via RC4 128 bit encryption
128 bit SSL browser access
Two level password security - up to 64 user accounts with separate profiles for each
External (Remote) authentication support: RADIUS LDAP LDAPS MS Active Directory
Support for IP/MAC Filter
Local and remote access logged and authenticated
Virtual Remote Desktop
Resizable remote desktop window
Message board allows logged in users to communicate with each other and allows a user to take exclusive control of the KVM functions
Mouse DynaSync
On-screen keyboard with multilanguage support
BIOS-level access
Hardware
16-port remote access KVM switch - monitor and control up to 16 computers from a single KVM console
Daisy chain up to 15 additional units - control up to 256 computers from a single console*
Auto-sensing of station’s position on daisy chained installations; no need for manual dip switch setting; front panel LED indicates station’s position
Hot pluggable - add or remove computers without having to power down the switch
Multiplatform support - Windows Linux Mac and Sun
Front panel USB hub allows connected computers to access USB peripherals
Dual Interface - supports PS/2 or USB keyboard and mouse computer connections with automatic interface detection
USB / PS/2 keyboard and mouse emulation - computers boot even when the console focus is elsewhere
Supports USB keyboards for PC Mac and Sun
Superior video quality - up to 2048 x 1536; DDC2B for the local console; up to 1600 x 1200 @ 60Hz / 24 bit color depth for remote sessions
Video DynaSync - stores the console monitor’s EDID (Extended Display Identification Data) to optimize display resolution
Rack mountable in a 19" (1U) system rack
Package Content
1x CS1716i KVM Switch
1x 2L-5202P PS/2 KVM Cable
1x 2L-5202U USB KVM Cable
1x LIN5-27X6-U21G Console Cable
1x Firmware Upgrade Cable
1x Mounting Kit
1x Foot Pad Set (4 pcs)
1x 0AD6-1605-24EG Power Adapter
1x Software CD
1x User Instructions
