CK500 Mid-Tower Case DETAILS MAKE THE DIFFERENCE The DeepCool CK500 Mid-Tower Case is a sleek and minimal case that delivers balanced airflow and noise performance for the modern-day builder with two pre-installed 140mm performance fans. QUICK-RELEASE SOLID FRONT PANEL Sleek curved edges offer a premium look and feel in a minimalistic design while still featuring large ventilation for more airflow. The solid steel panel adopts an easy quick-release magnetic connection. WIDE AND SPACIOUS INTERIOR Maximize potential with flexible configurations that meet the needs of any system setup. With space for large GPUs up to 380mm and CPU coolers up to 175mm in height the CK500 provides ample space without being too bulky. BIG AIR COOLING Two pre-installed DeepCool 140mm airflow-focused fans help concentrate cooling performance for lower temperatures and noise levels. CHOOSE YOUR COOLING CONFIGURATION The CK500 has great cooling capacity with up to 6x 120mm or 5x 140mm cooling fans and liquid cooling support for 280/360mm radiators through the front panel and 280/240mm radiators on the top panel. CONVENIENT STORAGE OPTIONS Install up to 2x 2.5in storage drives directly onto the motherboard tray with quick-release push-pins and 2x 3.5in HDDs on a tool-less tray design for extra simplicity. IMPROVED BUILDER EXPERIENCE
- Three dedicated dust-filters in front top and bottom with magnetic or quick-release attachments.
- The adjustable GPU anti-sag bracket can be positioned in two locations for various sized graphics cards.
- The full-sized tempered glass panel slides and holds in place before fastening with captive thumbscrews.
- Rubber Grommets and ample room behind the motherboard tray help with cable management.
- Independent PCIe baffles are reusable and easy to remove. MODERN FRONT I/O Features two USB 3.0 ports a single USB 3.1 Type-C port and a combination audio jack for the most important connections up close. Form Factor Mid Tower Motherboard E-ATX ATX Micro ATX Mini-ITX Colour Black Materials ABS SPCC Tempered Glass Drive Bays Internal 3.5": 2 Internal 2.5": 2 Power Supply Support ATX PS2 (maximum length: 160mm) I/O Panel 2 x USB 3.0 1 x Audio 1 x USB Type-C Expansion Slots: 7 Cooling Fans Compatibility Front: 3 x 120mm / 2 x 140mm (1 x 140mm fan installed) Top: 2 x 120mm / 2 x 140mm Rear: 1 x 120mm / 1 x 140mm (1 x 140mm fan installed) Liquid Cooler Compatibility Front: 120 / 140 / 240 / 280 / 360 Top: 120 / 140 / 240 / 280 Rear: 120 / 140 Clearances CPU Cooler Height Limit: 175mm VGA Length Limit: 380mm PSU Length Limit: 160mm Product Dimensions ( L x W x H ) 456mm x 230mm x 471mm Weight Net: 8KG
