Gigabyte X570S UD (rev. 1.0) AMD X570 Socket AM4 ATX

Supports Amd Ryzen 5000 Series/ Ryzen 5000 G-Series/ Ryzen 4000 G-Series/ Ryzen 3000 Series/ Ryzen 3000 G-Series/ Ryzen 2000 Series/ Ryzen 2000 G-Series Processors Dual Channel Ecc/ Non-Ecc Unbuffered Ddr4 4 Dimms Twin 12+2 Phases Digital Vrm Solution With 50A Drmos Fully Covered Thermal Design With High Coverage Mosfet Heatsinks Triple Ultra-Fast Nvme Pcie 4.0/3.0 X4 M.2 With Thermal Guard Fast 2.5Gbe Lan With Bandwidth Management Rear And Front Usb3.2 Type-C For Fast And Versatile Connections High Quality Audio Capacitors And Audio Noise Guard For Ultimate Audio Quality Smart Fan 6 Features Multiple Temperature Sensors Hybrid Fan Headers With Fan Stop Rgb Fusion 2.0 With Multi-Zone Addressable Led Light Show Design Support Addressable Led & Rgb Led Strips Q-Flash Plus Update Bios Without Installing The Cpu Memory And Graphics Card Performance To Unleash The Full Potential Of The Latest Amd Ryzen 5000 Series Processors The Motherboard Requires The Best Cpu Power Memory And Io Design. With The Best Quality Components And Gigabyte R&D Design Capability X570s Ud Is A True Beast Among Motherboards. Thermal X570s Ud Uses An Unprecedented And Innovative Thermal Design To Ensure The Best Cpu Chipset Ssd Stability And Low Temperatures Under Full Loading Application And Gaming. Connectivity A High-End Product Needs To Be Future-Proof So Your System Stays Up-To-Date With The Latest Technology. X570s Ud Provides All Next Generation Network Storage And Connectivity To Keep You Up To Speed. Ultra Durable Gigabyte Is Reputable For Its Product Durability And High Quality Manufacturing Process. Needless To Say We Use The Best Components We Can Find For The Gigabyte Motherboard And Reinforce Every Slot To Make Each Of Them Solid And Durable. Specification Cpu Amd Socket Am4 Support For: Amd Ryzen 5000 Series/ Ryzen 5000 G-Series/ Amd Ryzen 4000 G-Series/ Amd Ryzen 3000 Series/ Amd Ryzen 3000 G-Series/ Amd Ryzen 2000 Series/ Amd Ryzen 2000 G-Series Processors Chipset Amd X570 Memory 4 X Ddr4 Dimm Sockets Supporting Up To 128 Gb (32 Gb Single Dimm Capacity) Of System Memory Dual Channel Memory Architecture Support For Ddr4 5100(O.C.) / 4800(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200(O.C.) / 2933 / 2667 / 2400 / 2133 Mhz Memory Modules Support For Ecc Un-Buffered Dimm 1Rx8/2Rx8 Memory Modules

• Ecc Memory (Ecc Mode) Support Varies By Cpu Support For Non-Ecc Un-Buffered Dimm 1Rx8/2Rx8/1Rx16 Memory Modules Support For Extreme Memory Profile (Xmp) Memory Modules Onboard Graphics Integrated Graphics Processor: 1 X Hdmi Port Supporting A Maximum Resolution Of 4096X2160@ 60 Hz
• Support For Hdmi 2.1 Version Hdcp 2.3 And Hdr. Maximum Shared Memory Of 16 Gb Audio Realtek Audio Codec High Definition Audio 2/4/5.1/7.1-Channel Lan Realtek 2.5Gbe Lan Chip (2.5 Gbps/1 Gbps/100 Mbps) Expansion Slots 1 X Pci Express X16 Slot (Pciex16) Integrated In The Cpu: Amd Ryzen 5000 Series Processors/Amd Ryzen 3000 Series Processors Support Pcie 4.0 X16 Mode Amd Ryzen 4000 G-Series Processors/Amd Ryzen 2000 Series Processors Support Pcie 3.0 X16 Mode Amd Ryzen 3000 G-Series Processors/Amd Ryzen 2000 G-Series Processors Support Pcie 3.0 X8 Mode
• For Optimum Performance If Only One Pci Express Graphics Card Is To Be Installed Be Sure To Install It In The Pciex16 Slot. 1 X Pci Express X16 Slot (Pciex2) Integrated In The Chipset: Supporting Pcie 4.0(Note)/3.0 X2 Mode
• The Pciex2 Slot Shares Bandwidth With The Sata3 4 5 Connectors. The Sata3 4 5 Connectors Will Become Unavailable When A Device Is Installed In The Pciex2 Slot. 2 X Pci Express X1 Slots (Pciex11/Pciex12) Integrated In The Chipset: Supporting Pcie 4.0(Note)/3.0 (Note) For Amd Ryzen 5000 Series Processors/Amd Ryzen 3000 Series Processors Only. Storage Interface 1 X M.2 Connector (M2acpu) Integrated In The Cpu Supporting Socket 3 M Key Type 2242/2260/2280/22110 Ssds: Amd Ryzen 5000 Series Processors/Amd Ryzen 3000 Series Processors Support Sata And Pcie 4.0 X4/X2 Ssds Amd Ryzen 4000 G-Series Processors/Amd Ryzen 3000 G-Series Processors/Amd Ryzen 2000 Series Processors/Amd Ryzen 2000 G-Series Processors Support Sata And Pcie 3.0 X4/X2 Ssds 1 X M.2 Connector (M2csb) Integrated In The Chipset Supporting Socket 3 M Key Type 2242/2260/2280/22110 Ssds: Supporting Pcie 4.0(Note)/3.0 X4/X2 Ssds 1 X M.2 Connector (M2bsb) Integrated In The Chipset Supporting Socket 3 M Key Type 2242/2260/2280/22110 Ssds: Supporting Sata And Pcie 4.0(Note)/3.0 X4/X2 Ssds 6 X Sata 6Gb/S Connectors Integrated In The Chipset: Support For Raid 0 Raid 1 And Raid 10 (Note) For Amd Ryzen 5000 Series Processors/Amd Ryzen 3000 Series Processors Only. Usb Cpu: 4 X Usb 3.2 Gen 1 Ports On The Back Panel Chipset: 2 X Usb Type-C Ports With Usb 3.2 Gen 2 Support (1 Port On The Back Panel 1 Port Available Through The Internal Usb Header) 1 X Usb 3.2 Gen 2 Type-A Port (Red) On The Back Panel 2 X Usb 3.2 Gen 1 Ports Available Through The Internal Usb Header 6 X Usb 2.0/1.1 Ports (2 Ports On The Back Panel 4 Ports Available Through The Internal Usb Headers) Internal I/O Connectors 1 X 24-Pin Atx Main Power Connector 1 X 8-Pin Atx 12V Power Connector 1 X Cpu Fan Header 1 X Water Cooling Cpu Fan Header 3 X System Fan Headers 1 X System Fan/Water Cooling Pump Header 2 X Addressable Led Strip Headers 2 X Rgb Led Strip Headers 1 X Cpu Cooler Led Strip/Rgb Led Strip Header 3 X M.2 Socket 3 Connectors 6 X Sata 6Gb/S Connectors 1 X Front Panel Header 1 X Front Panel Audio Header 1 X Usb Type-C Header With Usb 3.2 Gen 2 Support 1 X Usb 3.2 Gen 1 Header 2 X Usb 2.0/1.1 Headers 1 X Trusted Platform Module (Tpm) Header (2X6 Pin For The Gc-Tpm2.0S Module Only) 1 X Clear Cmos Jumper Back Panel Connectors 1 X Ps/2 Keyboard/Mouse Port 1 X Hdmi Port 4 X Usb 3.2 Gen 1 Ports 2 X Usb 2.0/1.1 Ports 1 X Usb Type-C Port With Usb 3.2 Gen 2 Support 1 X Usb 3.2 Gen 2 Type-A Port (Red) 1 X Q-Flash Plus Button 1 X Rj-45 Port 6 X Audio Jacks I/O Controller Ite I/O Controller Chip Hardware Monitoring Voltage Detection Temperature Detection Fan Speed Detection Water Cooling Flow Rate Detection Fan Fail Warning Fan Speed Control
• Whether The Fan (Pump) Speed Control Function Is Supported Will Depend On The Fan (Pump) You Install. Bios 1 X 256 Mbit Flash Use Of Licensed Ami Uefi Bios Pnp 1.0A Dmi 2.7 Wfm 2.0 Sm Bios 2.7 Acpi 5.0 Unique Features Support For App Center
• Available Applications In App Center May Vary By Motherboard Model. Supported Functions Of Each Application May Also Vary Depending On Motherboard Specifications. @Bios Easytune Fast Boot Game Boost On/Off Charge Rgb Fusion Smart Backup System Information Viewer Support For Q-Flash Plus Support For Q-Flash Support For Xpress Install Bundled Software Norton Internet Security (Oem Version) Realtek 8125 Gaming Lan Bandwidth Control Utility Operating System Support For Windows 10 64-Bit Form Factor Atx Form Factor 30.5Cm X 24.4Cm
