Intellinet Transceiver Module Optical Gigabit Fiber WDM Bi-Directional SFP 1000Base-Lx (LC) Single-Mode Port 10km WDM (Rx1550/Tx1310) MSA Compliant Equivalent to Cisco GLC-BX-U Fibre Three Year Warranty

Gigabit Fibre SFP Optical Transceiver Module The new line of Intellinet Network Solutions Small Form Factor Pluggable (SFP) Transceivers provides the best combination of performance and affordability. These mini-GBIC (Gigabit Interface Converter) modules offer metal housing that reduces electromagnetic interference and increases durability. Small Size for High-Density Fibre Connections The transceiver is available in mini-GBIC form factor making it ideal for environments that require many fibre connections by taking up less space in your cabinet or computer room. Compatibility Compatibility in your network is everything and the Intellinet Network Solutions SFP Transceiver Module delivers. Use it with any Intellinet Network Solutions SFP equipped network switch or any other MSA compliant SFP enabled switch. And since the Intellinet Network Solutions SFP transceiver module is set to broadcast the vendor on GLC-BX-U compatibility to your Cisco gear is provided. Hot-Pluggable The Intellinet Network Solutions Gigabit Fibre WDM Bi-Directional SFP Optical Transceiver Module is fully hot-pluggable and that allows you to install the module without rebooting your network switch for uninterrupted network traffic. Digital Diagnostics Monitoring (DDM) The Intellinet Network Solutions Gigabit Fibre WDM Bi-Directional SFP Optical Transceiver Module supports standard digital diagnostics monitoring (DDM) functions also known as digital optical monitoring (DOM). The DDM/DOM function will monitor parameters of the SFP such as optical output power optical input power temperature laser bias current and transceiver supply voltage in real time. WDM (bi-directional wavelength division multiplexing) Technology Advantage The Intellinet Network Solutions Gigabit Fibre WDM Bi-Directional SFP Optical Transceiver Module utilizes a single strand of fibre to transmit network traffic on separate receive and transmit wavelengths (1310/1550 nm). This innovative technology effectively uses the two strands for two independent connections or to double the capacity without laying a second fibre cable. Note that this transceiver must be used in conjunction with Intellinet Network Solutions part number 507486.

• Fits any Intellinet Gigabit Ethernet switch with SFP module slots or any MSA or Cisco compliant SFP port
• Must be used with Gigabit Fibre WDM Bi-Directional SFP Optical Transceiver Module model 507486
• Data transfer rate: 1000 Mbps
• One 1000Base-LX single-mode Fibre LC port
• Fibre distance support: up to 10 km (6.2 mi.)
• WDM (wavelength division multiplexing) technology utilizes only one strand of fibre to transmit data on separate receive and transmit wavelengths
• Wavelengths: receive (RX) 1550 nm; transmit (TX) 1310 nm
• Compliant with the SFP Multi-Source Agreement (MSA)
• Compatible with the Cisco GLC-BX-U transceiver
• SFP standard form factor
• Supports digital diagnostics monitoring (DDM)
• Low EMI due to fully metallic housing
• Up to 1.25 Gbps bi-directional communication
• Supports hot-plugging
• Three-Year Warranty
