Kvr16s11/8 8Gb 2Rx8 1G X 64-Bit Pc3-12800 Cl11 204-Pin Sodimm Valueram’S 1G X 64-Bit (8Gb) Ddr3-1600 Cl11 Sdram (Synchronous Dram) 2Rx8 Memory Module Is Based On Sixteen 512M X 8-Bit Fbga Components. The Spd Is Programmed To Jedec Standard Latency Ddr3-1600 Timing Of 11-11-11 At 1.5V. This 204-Pin Sodimm Uses Gold Contact Fingers. Features • Jedec Standard 1.5V (1.425V ~1.575V) Power Supply • Vddq = 1.5V (1.425V ~ 1.575V) • 800Mhz Fck For 1600Mb/Sec/Pin • 8 Independent Internal Bank • Programmable Cas Latency: 11 10 9 8 7 6 • Programmable Additive Latency: 0 Cl - 2 Or Cl - 1 Clock • 8-Bit Pre-Fetch • Burst Length: 8 (Interleave Without Any Limit Sequential With Starting Address “000” Only) 4 With Tccd = 4 Which Does Not Allow Seamless Read Or Write [Either On The Fly Using A12 Or Mrs] • Bi-Directional Differential Data Strobe • Internal(Self) Calibration : Internal Self Calibration Through Zq Pin (Rzq : 240 Ohm ± 1%) • On Die Termination Using Odt Pin • Average Refresh Period 7.8Us At Lower Than Tcase 85°C 3.9Us At 85°C ≪ Tcase ≪ 95°C • Asynchronous Reset • Pcb : Height 1.180” (30.00Mm) Double Sided Component Kingston ValueRAM 8GB (1x8GB) DDR3 1600MHz Non-ECC 204-pin SODIMM Memory Module ValueRAM Kingston’s industry standard memory delivers award-winning performance and legendary Kingston reliability. When you know what you want you want ValueRAM.
