Wallplate Transmitter for USB-C

Atlona At-Ome-Ex-Tx-WpcProduct Key Features • Us One-Gang Enclosure For Wallplate Openings &Ndash; Interchangeable Black Or White Trim Kits. • Hdbasettm Transmitter For Usb-C (Av And Host Data) Power Control And Usb (Peripheral). • Usb 2.0 Interfacing And Extension Up To 330 Feet (100 Meters). • 4K/Uhd Capability @ 60 Hz With 4:2:0 Chroma Subsampling. • Hdcp 2.2 Compliant. • Remote Powering Over Hdbaset. • Also Available: Ome-Ex-Tx-Wp With Hdmi Input. Product Overview The Atlona At-Ome-Ex-Tx-Wpc Is An Hdbaset Transmitter With Usb-C Input. It Sends Video Up To 4K/60 4:2:0 Plus Embedded Audio Control And Usb Over Distances Up To 330 Feet (100 Meters). It Features A Us One-Gang Wallplate Form Factor And Includes Interchangeable Black And White Wallplates And Faceplates. Part Of The Omega™ Series Of Integration Products For Modern Av Communications And Collaboration The Ome-Ex-Tx-Wpc Is Hdcp 2.2 Compliant And Extends Rs-232 Control Signals. The Usb-C Input Is Ideal For Av Interfacing With Newer Mac? Chromebook™ And Windows? Pcs As Well As Smartphones And Tablets. With A Matching Hdbaset Receiver The Integrated Usb Extension Addresses The Challenge Of Connecting Between Usb Devices At Remote Locations And Is Ideal For Software Video Conferencing And Touch Or Interactive Displays. The Ome-Ex-Tx-Wpc Includes A Pc Host Interface Over Usb-C Plus A Usb 2.0 Interface For A Peripheral Device Such As A Speakerphone Microphone Or Keyboard And Mouse. This Transmitter Is Ideal For Use With Omega Series Receivers As Well As Switchers With Hdbaset Inputs. The Ome-Ex-Tx-Wpc Incorporates Many Popular Integration Convenience Features While Delivering Excellent Performance And Value For 4K Presentation And Video Conferencing Applications. The Ome-Ex-Tx-Wpc Can Be Remotely Powered By The Ome-Ex-Rx Ome-Sr21 Ome-Ps62 Or Other Omega Series Receiver Or Switcher. Product Applications • Complete System Integration: The Ome-Ex-Tx-Wpc And Ome-Sr21 Together Provide A Compact Yet Comprehensive And Cost-Effective Integration Solution With 4K Scaling Display Control Hdbaset Link Testing And Audio System Interfacing Provided By The Receiver. • Lecture Hall And Training Room Applications: This Transmitter Is Ideal For Extending Av Connectivity From An Ome-Ps62 In A Central Equipment Rack To Lecterns As Well As Remote Wall And Floor Box Locations Where Presenters Can Easily Access The System. • Video Conferencing: The Ome-Ex-Tx-Wpc And A Compatible Omega Series Receiver Or Switcher Are Ideal For Soft Codec And Web-Based Conferencing Applications With The Ability To Integrate With Pcs Cameras Speakerphones And Microphones. Product Compatibility The Ome-Ex-Tx-Wpc Is Not Compatible With The Atlona Hdvs-300 System For Usb Extension. Product Technical Features Us One-Gang Enclosure For Wallplate Openings &Ndash; Interchangeable Black Or White Trim Kits • Allows Inconspicuous Installation On A Wall In Furniture Or In A Floor Box. Includes Black And White Wallplates And Faceplates. • Meets End User Requirements For Conveniently Accessible Yet Discreet Av Connectivity. Usb-C Input For Av And Data* • Immediate Compatibility With Laptops And Tablets With Usb-C Ports Supporting Av. • No Need To Provide Usb-C To Hdmi Adapters.

• Usb-C Port Does Not Support Device Powering. Video Audio Power And Data Over Category Cable Utilizing Hdbaset Technology • Transmits 4K/Uhd Video Up To 330 Feet (100 Meters) With Cat6/6A/7 Cable Or Up To 295 Feet (90 Meters) Using Cat5e Cable. • Uses Easy-To-Integrate Category Cable For Low-Cost Reliable System Installation. Usb 2.0 Interfacing And Extension* Up To 330 Feet (100 Meters) • Usb-C Interface For Connection To A Host Pc Plus A Usb Type A Port For A Peripheral Device Such As A Microphone Speakerphone Or A Keyboard And Mouse. • Provides An Ideal Usb Integration Solution For Software Video Conferencing And Other Applications.
• Maximum 120 Mbps Data Rate Supported Over Hdbaset. 4K/Uhd Capability @ 60 Hz With 4:2:0 Chroma Subsampling • Compatible With Sources Up To 4K/60 4:2:0 And 4K/30 4:4:4. • Supports Hdmi Data Rates Up To 10 Gbps From Pcs Media Players And Ultra Hd Blu-Ray Players. Hdcp 2.2 Compliant • Adheres To Latest Specification For High-Bandwidth Digital Content Protection*. • Allows Protected Content Stream To Pass Between Authenticated Devices.
• Hdbaset Receiver Or Switcher Must Also Be Hdcp 2.2 Compliant. Remote Powering Over Hdbaset • Industry Standard Ieee 802.3Af Poe Is Supplied By An Atlona Receiver Or Switcher Over Hdbaset. • Allows Convenient Wall Floor Box Or Furniture Installation Without The Need For Local Ac Power. Multi-Channel Audio Compliant • Passes Through Multi-Channel Audio Formats. • Supports Pcm Dolby? Digital Dolby Digital Plus™ Dolby Truehd Dolby Atmos? Dts? Digital Surround™ Dts-Hd Master Audio™ And Dts:X?. Field-Updatable Firmware • Device Can Be Updated In The Field Via The Usb Port. Front Panel Power And Signal Status Leds • Led Indicators Provide Power And Hdbaset Link Status Information. • Provides Convenient Setup And Troubleshooting. Included Accessories • Installation Guide Interchangeable Black And White Wallplates And Faceplates. Award-Winning 10 Year Limited Product Warranty • Ensures Long-Term Product Reliability And Performance In Commercial And Residential Systems. • Specify Purchase And Install With Confidence. Dedicated Access For Usb-C Equipped Devices The Ome-Ex-Tx-Wpc Is Remotely Powered Over Hdbaset Allowing Easy Installation Anywhere Av Connectivity Is Needed For A Modern Laptop Or Tablet With Usb-C Output For Av. The Usb-C Port Also Serves As A Host Pc Interface For Software Video Conferencing Sessions And Touch-Enabled Displays.
